| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6209-72-1410) | INJECTION PUMP ASS'Y | 1 | SN: 150915- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0T8 TO A4010-F0T8. | ||||||
| ? | (DK105401-0660) | • GOVERNOR ASS'Y | 1 | SN: 150915- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0T8 AND A4010-E0T8. | ||||||
| ? | DK154011-0100 | • • NUT,LOCK | 1 | SN: 150915- |
|||
| ? | DK154022-5320 | • • COVER | 1 | SN: 150915- |
|||
| ? | DK154031-1300 | • • SCREW | 1 | SN: 150915- |
|||
| ? | DK139206-0600 | • • NUT | 1 | SN: 150915- |
|||
| ? | DK154036-0300 | • • PLUG | 2 | SN: 150915- |
|||
| ? | DK020106-5040 | • • BOLT | 6 | SN: 150915- |
|||
| ? | DK154010-0300 | • • SCREW | 1 | SN: 150915- |
|||
| ? | DK154063-6820 | • • COVER | 1 | SN: 150915- |
|||
| ? | DK029020-6210 | • • BOLT | 2 | SN: 150915- |
|||
| ? | DK020006-1640 | • • BOLT | 2 | SN: 150915- |
|||
| ? | DK154150-0400 | • • SPRING,GOVERNOR | 1 | SN: 150915- |
|||
| ? | DK154158-0920 | • • CAPSULE,SPRING | 1 | SN: 150915- |
|||
| ? | DK029201-2140 | • • NUT | 1 | SN: 150915- |
|||
| ? | DK026512-1540 | • • GASKET | 2 | SN: 150915- |
|||
| ? | DK154159-1200 | • • NUT,CAP | 1 | SN: 150915- |
|||
| ? | DK154200-7020 | • • LEVER ASS'Y,SWIVEL | 1 | SN: 150915- |
|||
| ? | DK154204-3000 | • • BUSHING | 1 | SN: 150915- |
|||
| ? | DK029631-8020 | • • O-RING | 2 | SN: 150915- |
|||
| ? | DK016010-1640 | • • RING,SNAP | 2 | SN: 150915- |
|||
| ? | DK139611-0000 | • • SEAL,OIL | 1 | SN: 150915- |
|||
| ? | DK139411-0000 | • • SHIM¤ 0.40MM | 1 | SN: 150915- |
|||
| ? | DK029311-1090 | • • SHIM¤ 0.30MM | A/R | SN: 150915- |
|||
| ? | DK154204-3100 | • • BUSHING | 1 | SN: 150915- |
|||
| ? | DK025803-1310 | • • KEY¤ 13MM | 1 | SN: 150915- |
|||
| ? | DK154206-2800 | • • COLLAR | 1 | SN: 150915- |
|||
| ? | DK154206-0200 | • • WASHER¤ 1.0MM | A/R | SN: 150915- |
|||
| ? | DK154237-0100 | • • PIN | 1 | SN: 150915- |
|||
| ? | DK154343-9220 | • • LEVER | 1 | SN: 150915- |
|||
| ? | DK154390-0300 | • • GASKET | 1 | SN: 150915- |
|||
| ? | DK029635-2020 | • • O-RING | 1 | SN: 150915- |
|||
| ? | DK154400-7420 | • • DIAPHRAGM | 1 | SN: 150915- |
|||
| ? | DK154400-4800 | • • ROD,PUSH | 1 | SN: 150915- |
|||
| ? | DK029330-8050 | • • GASKET | 2 | SN: 150915- |
|||
| ? | DK139308-0700 | • • WASHER,SPRING | 1 | SN: 150915- |
|||
| ? | DK013030-6040 | • • NUT | 1 | SN: 150915- |
|||
| ? | DK026510-1440 | • • GASKET | 1 | SN: 150915- |
|||
| ? | DK154401-2100 | • • BOLT | 1 | SN: 150915- |
|||
| ? | DK154411-6600 | • • SPRING | 1 | SN: 150915- |
|||
| ? | DK154404-5000 | • • COVER | 1 | SN: 150915- |
|||
| ? | DK020106-2540 | • • BOLT | 2 | SN: 150915- |
|||
| ? | DK154404-1100 | • • SCREW | 1 | SN: 150915- |
|||
| ? | DK023040-6040 | • • NUT | 1 | SN: 150915- |
|||
| ? | DK029711-0140 | • • EYE | 1 | SN: 150915- |
|||
| ? | DK029731-0180 | • • BOLT,EYE | 1 | SN: 150915- |
|||
| ? | DK029341-0110 | • • GASKET | 2 | SN: 150915- |
|||
| ? | DK029312-0180 | • • SHIM¤ 0.5MM | A/R | SN: 150915- |
|||
| ? | DK029312-0210 | • • SHIM¤ 0.2MM | A/R | SN: 150915- |
|||
| ? | DK154035-0320 | • • NUT,CAP | 1 | SN: 150915- |
|||
| ? | DK014110-6440 | • • WASHER,SPRING | 1 | SN: 150915- |
|||
| ? | DK154413-2600 | • • GASKET | 2 | SN: 150915- |
|||
| ? | DK029010-6310 | • • BOLT | 1 | SN: 150915- |
|||
| ? | DK026506-1040 | • • GASKET | 2 | SN: 150915- |
|||
| ? | DK154035-1600 | • • NUT,CAP | 1 | SN: 150915- |
|||
| ? | DK029310-9080 | • • SHIM | 1 | SN: 150915- |
