| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6209-72-1410) | INJECTION PUMP ASS'Y | 1 | SN: 150915- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0T8 TO A4010-F0T8. | ||||||
| ? | DK105401-0660 | • GOVERNOR ASS'Y | 1 | SN: 150915- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0T8 AND A4010-E0T8. | ||||||
| ? | DK154000-6300 | • • HOUSING | 1 | SN: 150915- |
|||
| ? | DK029632-5070 | • • O-RING | 1 | SN: 150915- |
|||
| ? | DK154007-2900 | • • PLUG | 1 | SN: 150915- |
|||
| ? | DK154007-0200 | • • ADAPTER | 1 | SN: 150915- |
|||
| ? | DK020018-1840 | • • BOLT | 1 | SN: 150915- |
|||
| ? | DK154350-1900 | • • PLATE | 1 | SN: 150915- |
|||
| ? | DK029010-6810 | • • BOLT | 6 | SN: 150915- |
|||
| ? | DK154010-0100 | • • SCREW | 1 | SN: 150915- |
|||
| ? | DK154011-0100 | • • NUT,LOCK | 1 | SN: 150915- |
|||
| ? | DK154050-9020 | • • LIMITER | 1 | SN: 150915- |
|||
| ? | DK154101-0120 | • • FLYWEIGHT ASS'Y | 1 | SN: 150915- |
|||
| ? | DK025803-1610 | • • KEY¤ 16MM,WOODRUFF | 1 | SN: 150915- |
|||
| ? | DK029321-2020 | • • WASHER,SPRING | 1 | SN: 150915- |
|||
| ? | DK029231-2030 | • • NUT | 1 | SN: 150915- |
|||
| ? | DK154123-0120 | • • SLEEVE | 1 | SN: 150915- |
|||
| ? | DK029311-0010 | • • SHIM¤ 0.20MM | A/R | SN: 150915- |
|||
| ? | DK029311-0180 | • • SHIM¤ 0.30MM | A/R | SN: 150915- |
|||
| ? | DK029311-0190 | • • SHIM¤ 0.40MM | A/R | SN: 150915- |
|||
| ? | DK139410-0000 | • • SHIM¤ 0.50MM | A/R | SN: 150915- |
|||
| ? | DK029311-0210 | • • SHIM¤ 1.00MM | A/R | SN: 150915- |
|||
| ? | DK139410-0100 | • • SHIM¤ 1.50MM | A/R | SN: 150915- |
|||
| ? | DK139410-3000 | • • SHIM¤ 2.00MM | A/R | SN: 150915- |
|||
| ? | DK139410-3100 | • • SHIM¤ 3.00MM | A/R | SN: 150915- |
|||
| ? | DK139410-3200 | • • SHIM¤ 4.00MM | A/R | SN: 150915- |
|||
| ? | DK154154-0701 | • • SPRING | 1 | SN: 150915- |
|||
| ? | DK154211-4120 | • • GUIDE LEVER ASS'Y | 1 | SN: 150915- |
|||
| ? | DK029310-5170 | • • SHIM | 3 | SN: 150915- |
|||
| ? | DK025520-1210 | • • PIN,SPLIT | 3 | SN: 150915- |
|||
| ? | DK154230-0120 | • • LINK | 1 | SN: 150915- |
|||
| ? | DK154236-4100 | • • LEVER,TENSION | 1 | SN: 150915- |
|||
| ? | DK154390-0000 | • • GASKET | 1 | SN: 150915- |
|||
| ? | DK154401-0220 | • • LEVER | 1 | SN: 150915- |
|||
| ? | DK154401-1320 | • • LINK | 1 | SN: 150915- |
|||
| ? | DK016010-0540 | • • RING,SNAP | 1 | SN: 150915- |
|||
| ? | DK154222-6200 | • • PIN | 1 | SN: 150915- |
|||
| ? | DK029300-4010 | • • WASHER | 1 | SN: 150915- |
|||
| ? | DK016010-0440 | • • RING,SNAP | 1 | SN: 150915- |
