| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6209-21-5120 | PAN,OIL | 1 | SN: 150915- |
|||
| ? | 6206-21-5150 | PLATE,UNDER | 1 | SN: 150915- |
|||
| ? | 01435-00816 | BOLT | 27 | SN: 150915- |
|||
| ? | 01435-00860 | BOLT | 2 | SN: 150915- |
|||
| ? | 01435-00830 | BOLT | 1 | SN: 150915- |
|||
| ? | 6144-51-6150 | BRACKET | 2 | SN: 150915- |
|||
| ? | 6137-71-3750 | SPACER | 2 | SN: 150915- |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 150915- |
|||
| ? | 6124-81-4290 | SPACER | 1 | SN: 150915- |
|||
| ? | 01642-20810 | WASHER | 1 | SN: 150915- |
|||
| ? | 6130-22-5290 | CLIP | 1 | SN: 150915- |
|||
| ? | 6204-21-5680 | VALVE | 1 | SN: 150915- |
|||
| ? | 07005-02216 | GASKET (K2) | 1 | SN: 150915- |
|||
| ? | 6209-51-6240 | TUBE,SUCTION | 1 | SN: 150915- |
|||
| ? | 6204-51-6122 | O-RING (K2) | 1 | SN: 160616- |
|||
| ? | □6204-51-6121 | O-RING | 1 | SN: 150915-160615 |
|||
| ? | 01435-20816 | BOLT | 1 | SN: 150915- |
|||
| ? | 01435-20812 | BOLT | 1 | SN: 150915- |
|||
| ? | 7861-92-4210 | SENSOR,OIL LEVEL | 1 | SN: 150915- |
|||
| ? | 7861-91-4220 | • O-RING | 1 | SN: 150915- |
|||
| ? | 01435-20612 | BOLT | 3 | SN: 150915- |
|||
| ? | 08036-10614 | CLIP | 1 | SN: 150915- |
|||
| ? | 08053-01512 | CLIP | 1 | SN: 150915- |
|||
| ? | 01435-21016 | BOLT | 1 | SN: 150915- |
|||
| ? | (09920-00150) | LIQUID GASKET,LG-7¤ 150G | A/R | SN: 150915- |
