| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6209-11-1100 | CYLINDER HEAD ASS'Y,VALVE LESS | 1 | SN: 150915- |
|||
| ? | ☆ | • HEAD,CYLINDER | 1 | SN: 150915- |
|||
| ? | 6204-19-1310 | • GUIDE,VALVE | 12 | SN: 150915- |
|||
| ? | 6209-11-1430 | • SEAT,INTAKE VALVE (STD) | 6 | SN: 150915- |
|||
| ? | 6209-19-1430 | • SEAT¤ 0.25MM,INTAKE VALVE (OS) | 6 | SN: 150915- |
|||
| ? | 6209-18-1430 | • SEAT¤ 0.50MM,INTAKE VALVE (OS) | 6 | SN: 150915- |
|||
| ? | 6207-11-1440 | • SEAT,EXHAUST VALVE (STD) | 6 | SN: 150915- |
|||
| ? | 6207-19-1440 | • SEAT¤ 0.25MM,EXHAUST VALVE (OS) | 6 | SN: 150915- |
|||
| ? | 6207-18-1440 | • SEAT¤ 0.50MM,EXHAUST VALVE (OS) | 6 | SN: 150915- |
|||
| ? | 07046-41008 | • PLUG | 6 | SN: 150915- |
|||
| ? | 07046-41810 | • PLUG | 13 | SN: 150915- |
|||
| ? | 07046-42216 | • PLUG | 5 | SN: 150915- |
|||
| ? | 07046-42516 | • PLUG | 15 | SN: 150915- |
|||
| ? | 02720-40104 | • PLUG | 1 | SN: 150915- |
|||
| ? | 6209-41-4110 | VALVE,INTAKE | 6 | SN: 150915- |
|||
| ? | 6209-41-4210 | VALVE,EXHAUST | 6 | SN: 150915- |
|||
| ? | 6204-41-4510 | SEAT,SPRING | 12 | SN: 150915- |
|||
| ? | 6204-41-4520 | COTTER | 24 | SN: 150915- |
|||
| ? | 6204-41-4431 | SPRING,VALVE | 12 | SN: 150915- |
|||
| ? | 6204-41-4541 | SEAL,VALVE | 6 | SN: 160616- |
|||
| ? | □6204-41-4540 | SEAL,VALVE (K1) | 6 | SN: 150915-160615 |
|||
| ? | 6204-41-4550 | CAP,VALVE STEM | 12 | SN: 150915- |
|||
| ? | 6204-13-1610 | BOLT | 25 | SN: 150915- |
|||
| ? | 01643-51232 | WASHER | 25 | SN: 150915- |
|||
| ? | 6206-11-1830 | GASKET,HEAD (K1) | 1 | SN: 150915- |
