| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6215-11-1100 | CYLINDER HEAD ASS'Y | 12 | SN: 12979- |
|||
| ? | □6212-11-1103 | CYLINDER HEAD ASS'Y | 12 | SN: 11797-12978 |
|||
| ? | ☆ | • HEAD,CYLINDER | 1 | SN: 12979- |
|||
| ? | ☆ | • HEAD,CYLINDER | 1 | SN: 11797-12978 |
|||
| ? | 6216-11-1330 | • INSERT,INTAKE VALVE (STD) | 2 | SN: 11797- |
|||
| ? | 6216-19-1330 | • INSERT¤ 0.25MM,INTAKE VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6216-18-1330 | • INSERT¤ 0.50MM,INTAKE VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6216-17-1330 | • INSERT¤ 0.75MM,INTAKE VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6216-16-1330 | • INSERT¤ 1.00MM,INTAKE VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6210-11-1321 | • INSERT,EXHAUST VALVE (STD) | 2 | SN: 11797- |
|||
| ? | 6210-19-1321 | • INSERT¤ 0.25MM,EXHAUST VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6210-18-1321 | • INSERT¤ 0.50MM,EXHAUST VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6210-17-1321 | • INSERT¤ 0.75MM,EXHAUST VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6210-16-1321 | • INSERT¤ 1.00MM,EXHAUST VALVE (OS) | 2 | SN: 11797- |
|||
| ? | 6212-16-1440 | • GUIDE,VALVE | 4 | SN: 11797- |
|||
| ? | 6210-11-1150 | • PIPE | 1 | SN: 11797- |
|||
| ? | 07000-73025 | • O-RING (K1) | 1 | SN: 12500- |
|||
| ? | ♦07000-63025 | • O-RING (K1) | 1 | SN: 11797-12499 |
|||
| ? | 6162-13-1150 | • PLUG,EXPANSION | 12 | SN: 11797- |
|||
| ? | 07046-41810 | • PLUG,EXPANSION | 1 | SN: 11797- |
|||
| ? | 6215-81-9510 | • PLUG | 1 | SN: 12979- |
|||
| ? | 07043-50108 | • PLUG | 1 | SN: 11797-12978 |
|||
| ? | 6215-81-9710 | • O-RING | 1 | SN: 12979- |
|||
| ? | 6210-11-1140 | • GUIDE,CROSSHEAD | 2 | SN: 11797- |
|||
| ? | 04020-00820 | • PIN,DOWEL | 2 | SN: 11797- |
|||
| ? | 6215-41-4110 | VALVE,INTAKE | 24 | SN: 11797- |
|||
| ? | 6215-41-4212 | VALVE,EXHAUST | 24 | SN: 11797- |
|||
| ? | 6212-41-4540 | SEAL,VALVE STEM (K1) | 48 | SN: 11797- |
|||
| ? | 6210-41-4530 | SEAT,SPRING¤ LOWER | 48 | SN: 11797- |
|||
| ? | 6210-41-4510 | SEAT,SPRING¤ UPPER | 48 | SN: 11797- |
|||
| ? | 6210-41-4430 | SPRING,OUTER | 48 | SN: 11797- |
|||
| ? | 6210-41-4440 | SPRING,INNER | 48 | SN: 11797- |
|||
| ? | 6136-41-4520 | COTTER,VALVE | 96 | SN: 11797- |
|||
| ? | 6210-41-5620 | CROSSHEAD | 24 | SN: 11797- |
|||
| ? | 6210-41-5641 | SCREW | 24 | SN: 12778- |
|||
| ? | □6210-41-5640 | SCREW | 24 | SN: 11797-12777 |
|||
| ? | 6162-43-5630 | NUT | 24 | SN: 11797- |
|||
| ? | STANDARD | ||||||
| ? | 6210-17-1813 | GASKET,HEAD (K1) | 12 | SN: 11797- |
|||
| ? | 6210-11-1820 | • GROMMET,OIL | 1 | SN: 11797- |
|||
| ? | 6210-11-1830 | • GROMMET,OIL | 1 | SN: 11797- |
|||
| ? | 6210-11-1840 | • GROMMET,OIL | 1 | SN: 11797- |
|||
| ? | 6210-11-1962 | • GROMMET,WATER | 1 | SN: 11797- |
|||
| ? | 6210-11-1952 | • GROMMET,WATER | 4 | SN: 11797- |
|||
| ? | OVERSIZE 0.40MM | ||||||
| ? | 6210-19-1813 | GASKET,HEAD | 12 | SN: 11797- |
|||
| ? | 6210-19-1820 | • GROMMET,OIL | 1 | SN: 11797- |
|||
| ? | 6210-19-1830 | • GROMMET,OIL | 1 | SN: 11797- |
|||
| ? | 6210-19-1840 | • GROMMET,OIL | 1 | SN: 11797- |
|||
| ? | 6210-19-1962 | • GROMMET,WATER | 1 | SN: 11797- |
|||
| ? | 6210-19-1952 | • GROMMET,WATER | 4 | SN: 11797- |
|||
| ? | 6210-11-1610 | BOLT,HEAD | 72 | SN: 11797- |
|||
| ? | 01438-01020 | BOLT,HEAD | 12 | SN: 11797- |
|||
| ? | 01050-31016 | BOLT,(FOR SHIPPING) | 12 | SN: 11797- |
|||
| ? | 07003-01015 | GASKET,(FOR SHIPPING) | 12 | SN: 11797- |
