| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6212-72-1421 | INJECTION PUMP ASS'Y | 1 | SN: 22964- |
|||
| ? | □6212-72-1420 | INJECTION PUMP ASS'Y | 1 | SN: 22885-22963 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B4F7 T0 A4010-G4F7. | ||||||
| ? | DK106068-2930 | • PUMP ASS'Y | 1 | SN: 22885- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B4F7 AND A4010-C4F7. | ||||||
| ? | DK134070-1020 | • • HOUSING | 1 | SN: 22885- |
|||
| ? | DK029040-6020 | • • • STUD | 3 | SN: 22885- |
|||
| ? | DK134311-0000 | • • • RING | 1 | SN: 22885- |
|||
| ? | DK134138-0100 | • • • STUD | 12 | SN: 22885- |
|||
| ? | DK016650-2230 | • • BEARING | 1 | SN: 22885- |
|||
| ? | DK134303-0500 | • • SHIM | 1 | SN: 22885- |
|||
| ? | DK139006-4200 | • • BOLT | 4 | SN: 22885- |
|||
| ? | DK134340-0100 | • • CAMSHAFT | 1 | SN: 22885- |
|||
| ? | DK134306-1000 | • • BEARING,CENTER | 1 | SN: 22885- |
|||
| ? | DK020106-2040 | • • BOLT | 2 | SN: 22885- |
|||
| ? | DK134306-1100 | • • BEARING,CENTER | 2 | SN: 22885- |
|||
| ? | DK020106-2040 | • • BOLT | 4 | SN: 22885- |
|||
| ? | DK035302-0600 | • • BEARING | 1 | SN: 22885- |
|||
| ? | DK134316-3300 | • • COVER | 1 | SN: 22885- |
|||
| ? | DK139634-0200 | • • SEAL,OIL | 1 | SN: 22885- |
|||
| ? | DK134314-0700 | • • SHIM¤ 0.10MM | A/R | SN: 22885- |
|||
| ? | DK134314-0800 | • • SHIM¤ 0.12MM | A/R | SN: 22885- |
|||
| ? | DK134314-0900 | • • SHIM¤ 0.14MM | A/R | SN: 22885- |
|||
| ? | DK134314-1000 | • • SHIM¤ 0.16MM | A/R | SN: 22885- |
|||
| ? | DK134314-1100 | • • SHIM¤ 0.18MM | A/R | SN: 22885- |
|||
| ? | DK134314-1200 | • • SHIM¤ 0.30MM | A/R | SN: 22885- |
|||
| ? | DK134314-1300 | • • SHIM¤ 0.50MM | A/R | SN: 22885- |
|||
| ? | DK139766-0000 | • • O-RING | 1 | SN: 22885- |
|||
| ? | DK134563-2500 | • • SLEEVE | 1 | SN: 22885- |
|||
| ? | DK134045-0100 | • • PLUG | 1 | SN: 22885- |
|||
| ? | DK026524-2940 | • • GASKET | 1 | SN: 22885- |
|||
| ? | DK139206-0400 | • • NUT | 3 | SN: 22885- |
|||
| ? | DK131041-0800 | • • GASKET | 1 | SN: 22885- |
|||
| ? | DK134047-0000 | • • PLUG | 6 | SN: 22885- |
|||
| ? | DK025806-2210 | • • KEY | 1 | SN: 22885- |
|||
| ? | DK014112-0440 | • • WASHER,SPRING | 1 | SN: 22885- |
|||
| ? | DK023012-0040 | • • NUT | 1 | SN: 22885- |
|||
| ? | DK156639-1500 | • • COUPLING | 1 | SN: 22885- |
|||
| ? | DK029731-4680 | • • BOLT,EYE | 1 | SN: 22885- |
|||
| ? | DK029341-4130 | • • GASKET | 2 | SN: 22885- |
|||
| ? | DK029111-0010 | • • PLUG | 1 | SN: 22885- |
|||
| ? | DK029331-0090 | • • GASKET | 1 | SN: 22885- |
|||
| ? | DK131425-1320 | • • VALVE,OVER FLOW | 1 | SN: 22885- |
|||
| ? | DK029341-4130 | • • GASKET | 2 | SN: 22885- |
|||
| ? | DK029731-4680 | • • BOLT,EYE | 1 | SN: 22885- |
|||
| ? | DK029341-4130 | • • GASKET | 2 | SN: 22885- |
