| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6210-71-3281 | SEAL,OIL (K2) | 1 | SN: 22885-26083 |
|||
| ? | (☒6210-71-3280) | SEAL,OIL | 1 | SN: (22885-24782) |
|||
| ? | 6210-21-1950 | FLANGE | 1 | SN: 22885-26083 |
|||
| ? | 6696-61-9921 | GASKET (K2) | 1 | SN: 22885-26083 |
|||
| ? | 01010-81225 | BOLT | 2 | SN: 22885-26083 |
|||
| ? | 6211-21-1900 | NOZZLE ASS'Y,PISTON COOLING | 6 | SN: 22885-26083 |
|||
| ? | 6211-21-1910 | • NOZZLE | 1 | SN: 22885-26083 |
|||
| ? | 02720-40104 | • PLUG | 1 | SN: 22885-26083 |
|||
| ? | 01437-01025 | BOLT | 6 | SN: 22885-26083 |
|||
| ? | 01641-21016 | WASHER | 6 | SN: 22885-26083 |
|||
| ? | 6211-22-2220 | LINER,CYLINDER | 6 | SN: 22885-26083 |
|||
| ? | 6210-21-2270 | SEAL,CREVICE (K2) | 6 | SN: 22885-26083 |
|||
| ? | 6210-21-2240 | O-RING,CENTER (K2) | 6 | SN: 22885-26083 |
|||
| ? | 6210-21-2230 | O-RING,LOWER (K2) | 6 | SN: 22885-26083 |
|||
| ? | 6210-21-1960 | COVER | 1 | SN: 22885-26083 |
|||
| ? | 6210-21-1971 | GASKET (K2) | 1 | SN: 22885-26083 |
|||
| ? | 01010-81025 | BOLT | 4 | SN: 22885-26083 |
|||
| ? | 07043-00415 | PLUG | 1 | SN: 22885-26083 |
|||
| ? | 7861-92-3320 | SENSOR,WATER TEMPERATURE | 1 | SN: 22885-26083 |
|||
| ? | 08053-01510 | CLIP | 1 | SN: 22885-26083 |
|||
| ? | 01010-81025 | BOLT | 1 | SN: 22885-26083 |
|||
| ? | 01640-21016 | WASHER | 1 | SN: 22885-26083 |
|||
| ? | 08073-10505 | SWITCH,OIL PRESSURE LOW | 1 | SN: 22885-26083 |
|||
| ? | 08073-10515 | SWITCH,OIL PRESSURE HIGH | 1 | SN: 22885-26083 |
|||
| ? | 6210-21-1940 | COVER | 1 | SN: 22885-26083 |
|||
| ? | 07000-03025 | O-RING | 1 | SN: 22885-26083 |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 22885-26083 |
|||
| ? | 6210-21-1820 | PLATE | 1 | SN: 22885-26083 |
|||
| ? | 6210-61-6551 | GASKET (K2) | 1 | SN: 22885-26083 |
|||
| ? | 01010-81025 | BOLT | 2 | SN: 22885-26083 |
|||
| ? | 07025-00050 | CAP,FILLER | 1 | SN: 22885-26083 |
|||
| ? | 01435-21014 | BOLT | 1 | SN: 22885-26083 |
|||
| ? | 6212-21-7111 | FILLER | 1 | SN: 22885-26083 |
|||
| ? | 6212-21-7810 | BRACKET | 1 | SN: 22885-26083 |
|||
| ? | 01010-81225 | BOLT | 1 | SN: 22885-26083 |
|||
| ? | 01435-01035 | BOLT | 1 | SN: 22885-26083 |
|||
| ? | 07283-25150 | CLIP | 1 | SN: 22885-26083 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 22885-26083 |
|||
| ? | 01599-01011 | NUT | 2 | SN: 24575-26083 |
|||
| ? | □01582-01008 | NUT | 2 | SN: 22885-24574 |
|||
| ? | 07040-11007 | PLUG | 1 | SN: 22885-26083 |
|||
| ? | 07005-01012 | GASKET (K2) | 1 | SN: 22885-26083 |
|||
| ? | 09920-00150 | LIQUID GASKET,LG-7¤ 150G | A/R | SN: 22885-26083 |
