| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-75-1580) | INJECTION PUMP A. | SN: 18669- |
||||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B6H2 TO A4010-G6H2. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK105664-0390 | • COUPLING ASS'Y | 1 | SN: 18669- |
|||
| ? | DK156631-2900 | • • COUPLING | 1 | SN: 18669- |
|||
| ? | DK156634-0100 | • • BOLT | 2 | SN: 18669- |
|||
| ? | DK156605-4320 | • • PLATE | 1 | SN: 18669- |
|||
| ? | DK156617-2400 | • • NUT | 2 | SN: 18669- |
|||
| ? | DK156633-4900 | • • BOLT | 2 | SN: 18669- |
|||
| ? | DK156609-9300 | • • COUPLING,CROSS | 1 | SN: 18669- |
|||
| ? | DK156633-4900 | • • BOLT | 2 | SN: 18669- |
|||
| ? | DK156605-4320 | • • PLATE | 1 | SN: 18669- |
|||
| ? | DK156633-4900 | • • BOLT | 2 | SN: 18669- |
|||
| ? | DK156633-5200 | • • BOLT | 1 | SN: 18669- |
|||
| ? | DK156615-2600 | • • WASHER | 1 | SN: 18669- |
