| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-23-5130 | PAN,OIL | 1 | SN: 18669- |
|||
| ? | 01010-81030 | BOLT | 47 | SN: 18669- |
|||
| ? | 01643-31032 | WASHER | 47 | SN: 20675- |
|||
| ? | □01602-01030 | WASHER,SPRING | 47 | SN: 18669-20674 |
|||
| ? | 209-62-15930 | BRACKET | 1 | SN: 18990- |
|||
| ? | 02720-41616 | PLUG | 2 | SN: 18669- |
|||
| ? | 426-01-11010 | VALVE ASS'Y,OIL PAN DRAIN | 1 | SN: 18669- |
|||
| ? | 426-01-11211 | • TUBE | 1 | SN: 18669- |
|||
| ? | 426-01-11231 | • TUBE | 1 | SN: 18669- |
|||
| ? | 424-01-11110 | • PLUG | 1 | SN: 18669- |
|||
| ? | 426-01-11221 | • HOSE | 1 | SN: 18669- |
|||
| ? | 07281-00359 | • CLAMP | 4 | SN: 18669- |
|||
| ? | 07000-73025 | O-RING | 1 | SN: 20294- |
|||
| ? | □07000-63025 | O-RING | 1 | SN: 18669-20293 |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 18669- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 18669- |
|||
| ? | 08034-00310 | BAND | 1 | SN: 18669- |
|||
| ? | 7861-92-4210 | SENSOR,OIL LEVEL | 1 | SN: 18669- |
|||
| ? | 01435-20612 | BOLT | 3 | SN: 18669- |
|||
| ? | 23S-44-14540 | PLATE | 1 | SN: 18669- |
|||
| ? | 08053-01512 | CLIP | 1 | SN: 18669- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 18669- |
|||
| ? | 01641-01016 | WASHER | 1 | SN: 18669- |
|||
| ? | 01010-81040 | BOLT | 1 | SN: 18669- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 18669- |
|||
| ? | 6162-55-6310 | TUBE,OIL SUCTION | 1 | SN: 18669- |
|||
| ? | 07000-E2060 | O-RING | 1 | SN: 18669- |
|||
| ? | 01010-81035 | BOLT | 2 | SN: 18669- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 19875- |
|||
| ? | □01602-01030 | WASHER,SPRING | 2 | SN: 18669-19874 |
|||
| ? | 6162-55-6340 | BRACKET | 1 | SN: 18669- |
|||
| ? | 01010-81025 | BOLT | 1 | SN: 18669- |
|||
| ? | 6110-23-6490 | SPACER | 1 | SN: 18669- |
|||
| ? | 01010-81025 | BOLT | 1 | SN: 18669- |
|||
| ? | 01580-01008 | NUT | 1 | SN: 18669- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 18669- |
|||
| ? | (09920-00150) | LIQUID GASKET,LG-7¤150G | A/R | SN: 18669- |
