| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-73-1572 | INJECTION PUMP A. | 1 | SN: 15137- |
|||
| ? | □6162-73-1571 | INJECTION PUMP A. | 1 | SN: 14513-15136 |
|||
| ? | □6162-73-1570 | INJECTION PUMP A. | 1 | SN: 13144-14512 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK103066-8420 | • PUMP ASS'Y | 1 | SN: 14513- |
|||
| ? | DK103066-8400 | • PUMP ASS'Y | 1 | SN: 13144-14512 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 AND 0452. | ||||||
| ? | DK133051-6320 | • • HOUSING | 1 | SN: 14513- |
|||
| ? | DK133051-5421 | • • HOUSING | 1 | SN: 13144-14512 |
|||
| ? | DK029040-6020 | • • • STUD | 3 | SN: 13144- |
|||
| ? | DK029112-4010 | • • • PLUG | 1 | SN: 13144- |
|||
| ? | DK133010-7600 | • • COVER | 1 | SN: 13144- |
|||
| ? | DK020106-1440 | • • BOLT | 16 | SN: 13144- |
|||
| ? | DK133011-2000 | • • GASKET | 1 | SN: 13144- |
|||
| ? | DK014110-6440 | • • WASHER,SPRING | 3 | SN: 13144- |
|||
| ? | DK013020-6040 | • • NUT | 3 | SN: 13144- |
|||
| ? | DK133041-0300 | • • GASKET | 1 | SN: 13144- |
|||
| ? | DK133106-0800 | • • DEFLECTOR | 6 | SN: 13144- |
|||
| ? | DK026510-1340 | • • GASKET | 6 | SN: 13144- |
|||
| ? | DK133210-0400 | • • SCREW | 6 | SN: 13144- |
|||
| ? | DK026510-1340 | • • GASKET | 6 | SN: 13144- |
|||
| ? | DK133371-2500 | • • CAMSHAFT | 1 | SN: 13144- |
|||
| ? | DK016603-3230 | • • BEARING | 2 | SN: 13144- |
|||
| ? | DK133302-0200 | • • RING | 2 | SN: 13144- |
|||
| ? | DK029313-0010 | • • SHIM¤ 0.10MM | A/R | SN: 13144- |
|||
| ? | DK029313-0020 | • • SHIM¤ 0.12MM | A/R | SN: 13144- |
|||
| ? | DK029313-0030 | • • SHIM¤ 0.14MM | A/R | SN: 13144- |
|||
| ? | DK029313-0040 | • • SHIM¤ 0.16MM | A/R | SN: 13144- |
|||
| ? | DK029313-0050 | • • SHIM¤ 0.18MM | A/R | SN: 13144- |
|||
| ? | DK029313-0060 | • • SHIM¤ 0.50MM | A/R | SN: 13144- |
|||
| ? | DK029313-0070 | • • SHIM¤ 1.00MM | A/R | SN: 13144- |
|||
| ? | DK133306-0200 | • • BEARING,CENTER | 1 | SN: 13144- |
|||
| ? | DK010208-4040 | • • BOLT | 2 | SN: 13144- |
|||
| ? | DK023500-8120 | • • WASHER | 2 | SN: 13144- |
|||
| ? | DK023650-8310 | • • WASHER,SPRING | 2 | SN: 13144- |
|||
| ? | DK029630-9020 | • • O-RING | 2 | SN: 13144- |
|||
| ? | DK139634-0200 | • • SEAL,OIL | 1 | SN: 13144- |
|||
| ? | DK133316-4800 | • • COVER | 1 | SN: 13144- |
|||
| ? | DK134563-2500 | • • SLEEVE | 1 | SN: 13144- |
|||
| ? | DK010208-2040 | • • BOLT | 6 | SN: 13144- |
|||
| ? | DK014110-8440 | • • WASHER,SPRING | 6 | SN: 13144- |
|||
| ? | DK156636-1600 | • • COUPLING | 1 | SN: 13144- |
|||
| ? | DK029637-6010 | • • O-RING | 1 | SN: 13144- |
|||
| ? | DK023012-0040 | • • NUT | 1 | SN: 13144- |
|||
| ? | DK014112-0440 | • • WASHER,SPRING | 1 | SN: 13144- |
|||
| ? | DK025806-2210 | • • KEY | 1 | SN: 13144- |
|||
| ? | DK131424-7320 | • • VALVE,OVER FLOW | 1 | SN: 14513- |
|||
| ? | DK133424-0420 | • • VALVE,OVER FLOW | 1 | SN: 13144-14512 |
|||
| ? | DK029731-4680 | • • BOLT,EYE | 1 | SN: 13144- |
|||
| ? | DK029341-4130 | • • GASKET | 4 | SN: 13144- |
|||
| ? | DK029731-4680 | • • BOLT,EYE | 1 | SN: 13144- |
|||
| ? | DK029341-4130 | • • GASKET | 2 | SN: 13144- |
