| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-73-1821 | TUBE | 1 | SN: 14259- |
|||
| ? | ♦6162-73-1820 | TUBE | 1 | SN: 13144-14258 |
|||
| ? | 07217-50712 | ELBOW | 1 | SN: 13144- |
|||
| ? | 07005-01012 | GASKET (K2) | 2 | SN: 13144- |
|||
| ? | 6130-85-4520 | CLIP | 1 | SN: 13144- |
|||
| ? | 01010-30820 | BOLT | 1 | SN: 13144- |
|||
| ? | 01602-00825 | WASHER,SPRING | 1 | SN: 13144- |
|||
| ? | 01640-20816 | WASHER | 1 | SN: 13144- |
|||
| ? | 6162-73-5421 | JOINT | 1 | SN: 13144- |
|||
| ? | 01010-31020 | BOLT | 1 | SN: 13144- |
|||
| ? | 01602-01030 | WASHER,SPRING | 1 | SN: 13144- |
|||
| ? | 6162-73-5950 | HOSE | 1 | SN: 13144- |
|||
| ? | 6162-73-5960 | HOSE,(EXTREME COLD TERRAIN SPEC.) | 1 | SN: 15320- |
|||
| ? | 07206-31014 | BOLT,JOINT | 1 | SN: 13144- |
|||
| ? | 07005-01412 | GASKET (K2) | 4 | SN: 13144- |
|||
| ? | 04434-51810 | CLIP | 1 | SN: 13144- |
|||
| ? | 6128-71-1932 | JOINT | 1 | SN: 13144- |
|||
| ? | 07206-31014 | BOLT,JOINT | 1 | SN: 13144- |
|||
| ? | 07005-01412 | GASKET (K2) | 2 | SN: 13144- |
|||
| ? | 07270-40411 | TUBE | 1 | SN: 13144- |
|||
| ? | 07270-50411 | TUBE,(EXTREME COLD TERRAIN SPEC.) | 1 | SN: 15320- |
|||
| ? | 07209-01040 | NIPPLE | 1 | SN: 13144- |
|||
| ? | 07285-00080 | CLIP | 2 | SN: 13144- |
|||
| ? | 04434-50810 | CLIP | 2 | SN: 13144- |
|||
| ? | (☒08036-10814) | CLIP | 2 | SN: (13144-13720) |
|||
| ? | 6162-73-8820 | PAD | 2 | SN: 13551- |
|||
| ? | 6162-73-8820 | PAD | 1 | SN: 13144-13550 |
|||
| ? | 08034-00519 | BAND | 2 | SN: 13551- |
|||
| ? | 08034-00519 | BAND | 1 | SN: 13144-13550 |
