| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-73-2370) | INJECTION PUMP A. | 1 | SN: 17220- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 TO 0482. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK105447-1611 | • GOVERNOR ASS'Y | 1 | SN: 17220- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0463 AND 0464. | ||||||
| ? | DK154002-3320 | • • HOUSING | 1 | SN: 17220- |
|||
| ? | DK154007-1600 | • • PLUG | 1 | SN: 17220- |
|||
| ? | DK139006-4100 | • • BOLT | 8 | SN: 17220- |
|||
| ? | DK154010-3900 | • • BOLT | 1 | SN: 17220- |
|||
| ? | DK154011-0100 | • • NUT,LOCK | 1 | SN: 17220- |
|||
| ? | DK153021-3120 | • • LIMITER | 1 | SN: 17220- |
|||
| ? | DK026524-3040 | • • GASKET | 1 | SN: 17220- |
|||
| ? | DK154100-9920 | • • FLYWEIGHT ASS'Y | 1 | SN: 17220- |
|||
| ? | DK025803-1310 | • • KEY¤ 13MM,WOODRUFF | 1 | SN: 17220- |
|||
| ? | DK025803-1610 | • • KEY¤ 16MM,WOODRUFF | 1 | SN: 17220- |
|||
| ? | DK029321-2020 | • • WASHER,SPRING | 1 | SN: 17220- |
|||
| ? | DK029231-2030 | • • NUT | 1 | SN: 17220- |
|||
| ? | DK154120-0100 | • • WASHER | 1 | SN: 17220- |
|||
| ? | DK029602-0020 | • • RING,SNAP | 1 | SN: 17220- |
|||
| ? | DK154121-0500 | • • GEAR | 1 | SN: 17220- |
|||
| ? | DK016610-2640 | • • BEARING | 1 | SN: 17220- |
|||
| ? | DK028102-0010 | • • BEARING | 1 | SN: 17220- |
|||
| ? | DK154134-0000 | • • SPACER | 1 | SN: 17220- |
|||
| ? | DK154122-0300 | • • COVER | 1 | SN: 17220- |
|||
| ? | DK029614-7020 | • • RING,SNAP | 1 | SN: 17220- |
|||
| ? | DK025803-1610 | • • KEY¤ 16MM | 1 | SN: 17220- |
|||
| ? | DK029321-2020 | • • WASHER,SPRING | 1 | SN: 17220- |
|||
| ? | DK029231-2030 | • • NUT | 1 | SN: 17220- |
|||
| ? | DK154123-1020 | • • SLEEVE | 1 | SN: 17220- |
|||
| ? | DK029311-0010 | • • SHIM¤ 0.20MM | A/R | SN: 17220- |
|||
| ? | DK029311-0180 | • • SHIM¤ 0.30MM | A/R | SN: 17220- |
|||
| ? | DK029311-0190 | • • SHIM¤ 0.40MM | A/R | SN: 17220- |
|||
| ? | DK139410-0000 | • • SHIM¤ 0.50MM | A/R | SN: 17220- |
|||
| ? | DK029311-0210 | • • SHIM¤ 1.00MM | A/R | SN: 17220- |
|||
| ? | DK139410-0100 | • • SHIM¤ 1.50MM | A/R | SN: 17220- |
|||
| ? | DK139410-3000 | • • SHIM¤ 2.00MM | A/R | SN: 17220- |
|||
| ? | DK139410-3100 | • • SHIM¤ 3.00MM | A/R | SN: 17220- |
|||
| ? | DK139410-3200 | • • SHIM¤ 4.00MM | A/R | SN: 17220- |
|||
| ? | DK154130-1820 | • • GEAR ASS'Y | 1 | SN: 17220- |
|||
| ? | DK153251-0100 | • • • DAMPER | 4 | SN: 17220- |
|||
| ? | DK139329-0000 | • • • WASHER | 1 | SN: 17220- |
|||
| ? | DK016020-2810 | • • • RING,SNAP | 1 | SN: 17220- |
|||
| ? | DK020106-2840 | • • BOLT | 3 | SN: 17220- |
|||
| ? | DK154154-2900 | • • SPRING | 1 | SN: 17220- |
|||
| ? | DK154156-0100 | • • TUBE | 2 | SN: 17220- |
|||
| ? | DK154186-1520 | • • CAPSULE,SPRING | 1 | SN: 17220- |
|||
| ? | DK029201-6010 | • • NUT | 1 | SN: 17220- |
|||
| ? | DK154217-2820 | • • GUIDE LEVER ASS'Y | 1 | SN: 17220- |
|||
| ? | DK029310-5170 | • • SHIM | 3 | SN: 17220- |
|||
| ? | DK025520-1210 | • • PIN,SPLIT | 2 | SN: 17220- |
|||
| ? | DK154230-0220 | • • LINK | 1 | SN: 17220- |
|||
| ? | DK016010-0540 | • • RING,SNAP | 1 | SN: 17220- |
|||
| ? | DK154232-0400 | • • CONNECTOR | 1 | SN: 17220- |
|||
| ? | DK029050-5040 | • • SCREW | 2 | SN: 17220- |
|||
| ? | DK154236-5721 | • • LEVER,TENSION | 1 | SN: 17220- |
|||
| ? | DK154371-5600 | • • GASKET | 1 | SN: 17220- |
|||
| ? | DK154401-4420 | • • LINK | 1 | SN: 17220- |
|||
| ? | DK154401-1020 | • • LINK | 1 | SN: 17220- |
|||
| ? | DK016010-0540 | • • RING,SNAP | 1 | SN: 17220- |
|||
| ? | DK154222-6200 | • • PIN | 1 | SN: 17220- |
|||
| ? | DK029300-4010 | • • WASHER | 1 | SN: 17220- |
|||
| ? | DK016010-0440 | • • RING,SNAP | 1 | SN: 17220- |
