| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6162-73-2370) | INJECTION PUMP A. | 1 | SN: 17220- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 TO 0482. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | (DK106068-2810) | • PUMP ASS'Y | 1 | SN: 17220- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 AND 0454. | ||||||
| ? | DK134147-5120 | • • PLUNGER BLOCK A. | 6 | SN: 17220- |
|||
| ? | DK134173-3120 | • • • PLUNGER ASS'Y | 1 | SN: 17220- |
|||
| ? | DK134110-8020 | • • • VALVE,DELIVERY | 1 | SN: 17220- |
|||
| ? | DK134171-0120 | • • • HOLDER | 1 | SN: 17220- |
|||
| ? | DK016500-1800 | • • • O-RING | 1 | SN: 17220- |
|||
| ? | DK134117-1700 | • • • STOPPER | 1 | SN: 17220- |
|||
| ? | DK134112-2200 | • • • SPRING | 1 | SN: 17220- |
|||
| ? | DK134115-0300 | • • • GASKET | 1 | SN: 17220- |
|||
| ? | DK134135-0300 | • • • DEFLECTOR | 1 | SN: 17220- |
|||
| ? | DK029602-0010 | • • • RING,SNAP | 1 | SN: 17220- |
|||
| ? | DK139727-0200 | • • • O-RING | 1 | SN: 17220- |
|||
| ? | DK029631-5020 | • • • O-RING | 2 | SN: 17220- |
|||
| ? | DK139400-0900 | • • SHIM¤ 0.500MM | A/R | SN: 17220- |
|||
| ? | DK139400-1000 | • • SHIM¤ 0.525MM | A/R | SN: 17220- |
|||
| ? | DK139400-1100 | • • SHIM¤ 0.550MM | A/R | SN: 17220- |
|||
| ? | DK139400-1200 | • • SHIM¤ 0.575MM | A/R | SN: 17220- |
|||
| ? | DK139400-1300 | • • SHIM¤ 0.600MM | A/R | SN: 17220- |
|||
| ? | DK139400-1400 | • • SHIM¤ 0.625MM | A/R | SN: 17220- |
|||
| ? | DK139400-1500 | • • SHIM¤ 0.650MM | A/R | SN: 17220- |
|||
| ? | DK139400-1600 | • • SHIM¤ 0.675MM | A/R | SN: 17220- |
|||
| ? | DK139400-1700 | • • SHIM¤ 0.700MM | A/R | SN: 17220- |
|||
| ? | DK139400-1800 | • • SHIM¤ 0.725MM | A/R | SN: 17220- |
|||
| ? | DK139400-1900 | • • SHIM¤ 0.750MM | A/R | SN: 17220- |
|||
| ? | DK139400-2000 | • • SHIM¤ 0.775MM | A/R | SN: 17220- |
|||
| ? | DK139400-2100 | • • SHIM¤ 0.800MM | A/R | SN: 17220- |
|||
| ? | DK139400-2200 | • • SHIM¤ 0.825MM | A/R | SN: 17220- |
|||
| ? | DK139400-2300 | • • SHIM¤ 0.850MM | A/R | SN: 17220- |
|||
| ? | DK139400-2400 | • • SHIM¤ 0.875MM | A/R | SN: 17220- |
|||
| ? | DK139400-2500 | • • SHIM¤ 0.900MM | A/R | SN: 17220- |
|||
| ? | DK139400-2600 | • • SHIM¤ 0.925MM | A/R | SN: 17220- |
|||
| ? | DK139400-2700 | • • SHIM¤ 0.950MM | A/R | SN: 17220- |
|||
| ? | DK139400-2800 | • • SHIM¤ 0.975MM | A/R | SN: 17220- |
|||
| ? | DK139400-2900 | • • SHIM¤ 1.000MM | A/R | SN: 17220- |
|||
| ? | DK139400-3000 | • • SHIM¤ 1.025MM | A/R | SN: 17220- |
|||
| ? | DK139400-3100 | • • SHIM¤ 1.050MM | A/R | SN: 17220- |
|||
| ? | DK139400-3200 | • • SHIM¤ 1.075MM | A/R | SN: 17220- |
|||
| ? | DK139400-3300 | • • SHIM¤ 1.100MM | A/R | SN: 17220- |
|||
| ? | DK139400-3400 | • • SHIM¤ 1.125MM | A/R | SN: 17220- |
|||
| ? | DK139400-3500 | • • SHIM¤ 1.150MM | A/R | SN: 17220- |
|||
| ? | DK139400-3600 | • • SHIM¤ 1.175MM | A/R | SN: 17220- |
|||
| ? | DK139400-3700 | • • SHIM¤ 1.200MM | A/R | SN: 17220- |
|||
| ? | DK139400-3800 | • • SHIM¤ 1.225MM | A/R | SN: 17220- |
|||
| ? | DK139400-3900 | • • SHIM¤ 1.250MM | A/R | SN: 17220- |
|||
| ? | DK139400-4000 | • • SHIM¤ 1.275MM | A/R | SN: 17220- |
|||
| ? | DK139400-4100 | • • SHIM¤ 1.300MM | A/R | SN: 17220- |
|||
| ? | DK139400-4200 | • • SHIM¤ 1.325MM | A/R | SN: 17220- |
|||
| ? | DK139400-4300 | • • SHIM¤ 1.350MM | A/R | SN: 17220- |
|||
| ? | DK139400-4400 | • • SHIM¤ 1.375MM | A/R | SN: 17220- |
|||
| ? | DK139400-4500 | • • SHIM¤ 1.400MM | A/R | SN: 17220- |
|||
| ? | DK139400-4600 | • • SHIM¤ 1.425MM | A/R | SN: 17220- |
|||
| ? | DK139400-4700 | • • SHIM¤ 1.450MM | A/R | SN: 17220- |
|||
| ? | DK139400-4800 | • • SHIM¤ 1.475MM | A/R | SN: 17220- |
|||
| ? | DK139400-4900 | • • SHIM¤ 1.500MM | A/R | SN: 17220- |
|||
| ? | DK139400-5000 | • • SHIM¤ 1.525MM | A/R | SN: 17220- |
|||
| ? | DK139400-5100 | • • SHIM¤ 1.550MM | A/R | SN: 17220- |
|||
| ? | DK139400-5200 | • • SHIM¤ 1.575MM | A/R | SN: 17220- |
|||
| ? | DK139400-5300 | • • SHIM¤ 1.600MM | A/R | SN: 17220- |
|||
| ? | DK139400-5400 | • • SHIM¤ 1.625MM | A/R | SN: 17220- |
|||
| ? | DK139400-5500 | • • SHIM¤ 1.650MM | A/R | SN: 17220- |
|||
| ? | DK139400-5600 | • • SHIM¤ 1.675MM | A/R | SN: 17220- |
|||
| ? | DK139400-5700 | • • SHIM¤ 1.700MM | A/R | SN: 17220- |
|||
| ? | DK139400-5800 | • • SHIM¤ 1.725MM | A/R | SN: 17220- |
|||
| ? | DK139400-5900 | • • SHIM¤ 1.750MM | A/R | SN: 17220- |
|||
| ? | DK139400-6000 | • • SHIM¤ 1.775MM | A/R | SN: 17220- |
|||
| ? | DK139400-6100 | • • SHIM¤ 1.800MM | A/R | SN: 17220- |
|||
| ? | DK139400-6200 | • • SHIM¤ 1.825MM | A/R | SN: 17220- |
|||
| ? | DK139400-6300 | • • SHIM¤ 1.850MM | A/R | SN: 17220- |
|||
| ? | DK139400-6400 | • • SHIM¤ 1.875MM | A/R | SN: 17220- |
|||
| ? | DK139400-6500 | • • SHIM¤ 1.900MM | A/R | SN: 17220- |
|||
| ? | DK139400-6600 | • • SHIM¤ 1.925MM | A/R | SN: 17220- |
|||
| ? | DK139400-6700 | • • SHIM¤ 1.950MM | A/R | SN: 17220- |
|||
| ? | DK139400-6800 | • • SHIM¤ 1.975MM | A/R | SN: 17220- |
|||
| ? | DK134132-0300 | • • WASHER | 12 | SN: 17220- |
|||
| ? | DK139210-0200 | • • NUT | 12 | SN: 17220- |
|||
| ? | DK134001-0000 | • • BUSHING | 2 | SN: 17220- |
|||
| ? | DK134256-0000 | • • RACK,CONTROL | 1 | SN: 17220- |
|||
| ? | DK024030-2030 | • • PIN | 1 | SN: 17220- |
|||
| ? | DK134222-0000 | • • BUSHING | 1 | SN: 17220- |
|||
| ? | DK134241-0620 | • • SLEEVE,CONTROL | 6 | SN: 17220- |
|||
| ? | DK134216-0000 | • • SEAT,SPRING | 6 | SN: 17220- |
|||
| ? | DK134215-0800 | • • SPRING | 6 | SN: 17220- |
|||
| ? | DK134217-0700 | • • SEAT,SPRING | 6 | SN: 17220- |
|||
| ? | DK134563-2700 | • • SEAT | 6 | SN: 17220- |
|||
| ? | DK134200-0820 | • • TAPPET ASS'Y | 4 | SN: 17220- |
|||
| ? | DK134204-0200 | • • • ROLLER | 1 | SN: 17220- |
|||
| ? | DK134203-0000 | • • • PIN | 1 | SN: 17220- |
|||
| ? | DK131206-0500 | • • • GUIDE | 1 | SN: 17220- |
|||
| ? | DK134200-0720 | • • TAPPET ASS'Y | 2 | SN: 17220- |
|||
| ? | DK134204-0200 | • • • ROLLER | 1 | SN: 17220- |
|||
| ? | DK134203-0000 | • • • PIN | 1 | SN: 17220- |
|||
| ? | DK131206-0500 | • • • GUIDE | 1 | SN: 17220- |
|||
| ? | DK134043-0800 | • • COVER | 1 | SN: 17220- |
|||
| ? | DK134042-1400 | • • GASKET | 1 | SN: 17220- |
|||
| ? | DK012206-1640 | • • SCREW | 12 | SN: 17220- |
