| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6162-13-1102 | CYLINDER HEAD ASS'Y,VALVE LESS | 6 | SN: 14991- |
|||
| ? | ☆ | • HEAD,CYLINDER | 1 | SN: 11763- |
|||
| ? | 6162-13-1130 | • SLEEVE | 1 | SN: 11763- |
|||
| ? | 6162-12-1152 | • O-RING (K1) | 1 | SN: 11763- |
|||
| ? | 6162-13-1330 | • INSERT,INTAKE VALVE (STD) | 2 | SN: 11763- |
|||
| ? | 6162-19-1330 | • INSERT¤ 0.25MM,INTAKE VALVE (OS) | 2 | SN: 11763- |
|||
| ? | 6162-18-1330 | • INSERT¤ 0.50MM,INTAKE VALVE (OS) | 2 | SN: 11763- |
|||
| ? | 6162-17-1330 | • INSERT¤ 0.75MM,INTAKE VALVE (OS) | 2 | SN: 11763- |
|||
| ? | 6162-16-1330 | • INSERT¤ 1.00MM,INTAKE VALVE (OS) | 2 | SN: 11763- |
|||
| ? | 6162-13-1322 | • INSERT,EXHAUST VALVE (STD) | 2 | SN: 14991- |
|||
| ? | 6162-19-1322 | • INSERT¤ 0.25MM,EXHAUST VALVE (OS) | 2 | SN: 14991- |
|||
| ? | 6162-18-1322 | • INSERT¤ 0.50MM,EXHAUST VALVE (OS) | 2 | SN: 14991- |
|||
| ? | 6162-17-1322 | • INSERT¤ 0.75MM,EXHAUST VALVE (OS) | 2 | SN: 14991- |
|||
| ? | 6162-16-1322 | • INSERT¤ 1.00MM,EXHAUST VALVE (OS) | 2 | SN: 14991- |
|||
| ? | 6162-16-1341 | • GUIDE,VALVE | 4 | SN: 11763- |
|||
| ? | 6162-13-1160 | • TUBE,PUSH ROD | 2 | SN: 11763- |
|||
| ? | 07000-63028 | • O-RING (K1) | 2 | SN: 11763- |
|||
| ? | 6162-13-1140 | • GUIDE,CROSSHEAD | 2 | SN: 11763- |
|||
| ? | 07043-50108 | • PLUG | 4 | SN: 11763- |
|||
| ? | 07043-50211 | • PLUG | 1 | SN: 11763- |
|||
| ? | 07043-50617 | • PLUG | 5 | SN: 11763- |
|||
| ? | 6162-13-1150 | • PLUG,EXPANSION | 12 | SN: 11763- |
|||
| ? | 6162-13-1410 | • PIN | 2 | SN: 11763- |
|||
| ? | 6162-43-4110 | VALVE,INTAKE | 12 | SN: 11763- |
|||
| ? | 6164-41-4211 | VALVE,EXHAUST | 12 | SN: 14991- |
|||
| ? | 6162-42-4410 | SPRING,OUTER | 24 | SN: 11763- |
|||
| ? | 6162-43-4420 | SPRING,INNER | 24 | SN: 11763- |
|||
| ? | 6162-43-4510 | SEAT,SPRING | 24 | SN: 11763- |
|||
| ? | 6162-42-4520 | COTTER,VALVE | 48 | SN: 11763- |
|||
| ? | 6162-43-4430 | SEAT,SPRING | 24 | SN: 11763- |
|||
| ? | 6162-43-5610 | CROSSHEAD | 12 | SN: 11763- |
|||
| ? | 6162-43-5640 | SCREW,ADJUST | 12 | SN: 11763- |
|||
| ? | 6127-41-5630 | NUT | 12 | SN: 11763- |
|||
| ? | STANDARD | ||||||
| ? | 6162-13-1812 | GASKET,HEAD (K1) | 6 | SN: 12243- |
|||
| ? | (☒6162-17-1811) | GASKET,HEAD (K1) | 6 | SN: (12243-14041) |
|||
| ? | □6162-13-1811 | GASKET,HEAD | 6 | SN: 12109-12242 |
|||
| ? | □6162-13-1810 | GASKET,HEAD | 6 | SN: 11763-12108 |
|||
| ? | 6162-13-1820 | • GROMMET,OIL | 2 | SN: 12243- |
|||
| ? | 6162-13-1832 | • GROMMET,WATER | 1 | SN: 12243- |
|||
| ? | (☒6162-13-1831) | • GROMMET,WATER | 1 | SN: (12243-14041) |
|||
| ? | 6162-13-1840 | • GROMMET,OIL | 1 | SN: 12243- |
|||
| ? | 6162-13-1851 | • GROMMET,WATER | 1 | SN: 12243- |
|||
| ? | (☒6162-13-1850) | • GROMMET,WATER | 1 | SN: (12243-14041) |
|||
| ? | OVERSIZE 0.40MM | ||||||
| ? | 6162-19-1812 | GASKET,HEAD | 6 | SN: 12243- |
|||
| ? | (☒6162-19-1811) | GASKET,HEAD | 6 | SN: (12243-14041) |
|||
| ? | 6162-19-1820 | • GROMMET,OIL | 2 | SN: 12243- |
|||
| ? | 6162-19-1832 | • GROMMET,WATER | 1 | SN: 12243- |
|||
| ? | (☒6162-19-1831) | • GROMMET,WATER | 1 | SN: (12243-14041) |
|||
| ? | 6162-19-1840 | • GROMMET,OIL | 1 | SN: 12243- |
|||
| ? | 6162-19-1851 | • GROMMET,WATER | 1 | SN: 12243- |
|||
| ? | (☒6162-19-1850) | • GROMMET,WATER | 1 | SN: (12243-14041) |
|||
| ? | 6162-13-1611 | BOLT | 36 | SN: 12109- |
|||
| ? | ♦6162-13-1610 | BOLT | 36 | SN: 11763-12108 |
|||
| ? | 6162-13-1620 | WASHER | 36 | SN: 11763- |
