| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6210-81-3112 | AIR COMPRESSOR ASS'Y | 1 | SN: 20576- |
|||
| ? | □6210-81-3111 | AIR COMPRESSOR ASS'Y | 1 | SN: 17626-20575 |
|||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK487000-6500 | • CASE,CRANK | 1 | SN: 17626- |
|||
| ? | DK487653-0300 | • CRANKSHAFT | 1 | SN: 17626- |
|||
| ? | DK035620-6000 | • BEARING | 1 | SN: 17626- |
|||
| ? | DK036202-0700 | • BEARING | 1 | SN: 17626- |
|||
| ? | DK487003-7301 | • COVER | 1 | SN: 17626- |
|||
| ? | DK487061-4300 | • O-RING (K8) | 1 | SN: 17626- |
|||
| ? | DK487061-4500 | • O-RING (K8) | 1 | SN: 17626- |
|||
| ? | DK487061-3700 | • O-RING (K8) | 1 | SN: 17626- |
|||
| ? | DK487001-3200 | • CYLINDER | 1 | SN: 17626- |
|||
| ? | DK487013-2100 | • CONNECTING ROD A. | 1 | SN: 17626- |
|||
| ? | DK487009-2000 | • PISTON | 1 | SN: 20576- |
|||
| ? | DK487010-4720 | • RING KIT,PISTON | 1 | SN: 20576- |
|||
| ? | DK487012-0100 | • PIN,PISTON | 1 | SN: 17626- |
|||
| ? | DK016110-1610 | • RING,SNAP | 2 | SN: 17626- |
|||
| ? | DK487020-2200 | • GASKET (K8) | 1 | SN: 17626- |
|||
| ? | DK487018-5221 | • CYLINDER HEAD ASS'Y | 1 | SN: 20576- |
|||
| ? | □DK487018-5220 | • CYLINDER HEAD ASS'Y | 1 | SN: 17626-20575 |
|||
| ? | DK487018-5320 | • • CYLINDER HEAD A. | 1 | SN: 17626- |
|||
| ? | DK487018-5300 | • • • HEAD,CYLINDER | 1 | SN: 17626- |
|||
| ? | DK487061-4000 | • • • O-RING (K8) | 1 | SN: 17626- |
|||
| ? | DK487042-1100 | • • • GUIDE,SPRING | 1 | SN: 17626- |
|||
| ? | DK487061-4100 | • • • O-RING (K8) | 1 | SN: 17626- |
|||
| ? | DK487031-2000 | • • • SPRING,DELIVERY VALVE | 1 | SN: 17626- |
|||
| ? | DK487026-1700 | • • • VALVE,PLATE | 1 | SN: 17626- |
|||
| ? | DK487030-2200 | • • • SEAT,DELIVERY VALVE | 1 | SN: 17626- |
|||
| ? | DK487024-1300 | • • • SPRING,UNLOADER VALVE | 1 | SN: 17626- |
|||
| ? | DK487039-0300 | • • • GASKET (K8) | 1 | SN: 17626- |
|||
| ? | DK487025-1000 | • • • SEAT,INTAKE VALVE | 1 | SN: 17626- |
|||
| ? | DK487026-1601 | • • • VALVE,PLATE | 1 | SN: 17626- |
|||
| ? | DK487027-1200 | • • • SPRING,INTAKE VALVE | 1 | SN: 17626- |
|||
| ? | DK487028-1700 | • • • GUIDE,INTAKE VALVE | 1 | SN: 17626- |
|||
| ? | DK487021-5020 | • • UNLOADER VALVE A. | 1 | SN: 20576- |
|||
| ? | □DK487021-2320 | • • UNLOADER VALVE A. | 1 | SN: 17626-207575 |
|||
| ? | DK487073-0900 | • FLANGE | 1 | SN: 17626- |
|||
| ? | DK156603-4400 | • BOLT | 4 | SN: 17626- |
|||
| ? | DK010110-2570 | • BOLT | 4 | SN: 17626- |
|||
| ? | DK487088-0000 | • BOLT | 2 | SN: 17626- |
|||
| ? | DK014110-8440 | • WASHER,SPRING | 4 | SN: 17626- |
|||
| ? | DK014111-0440 | • WASHER,SPRING | 4 | SN: 17626- |
|||
| ? | DK487351-0800 | • WASHER,SPRING | 4 | SN: 17626- |
|||
| ? | DK014020-8140 | • WASHER | 4 | SN: 17626- |
|||
| ? | DK487017-1600 | • BOLT | 4 | SN: 17626- |
|||
| ? | DK487088-0100 | • BOLT | 2 | SN: 17626- |
