| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-813-4222 | STARTING MOTOR ASS'Y,(11KW) | 1 | SN: 17626- |
|||
| ? | THE SAWAFUJI DENKI PART NUMBER IS THAT SD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | SD1310-10030X0 | • YOKE ASS'Y | 1 | SN: 17626- |
|||
| ? | SD4141-26410X0 | • PACKING | 2 | SN: 17626- |
|||
| ? | SD2240-24010X0 | • BRACKET,REAR | 1 | SN: 17626- |
|||
| ? | SD1331-04300X0 | • BRUSH HOLDER ASS'Y | 1 | SN: 17626- |
|||
| ? | SD5250-02800X0 | • • SPRING,BRUSH | 4 | SN: 17626- |
|||
| ? | SD5000-10500X0 | • SCREW | 2 | SN: 17626- |
|||
| ? | SD6414-04510X0 | • O-RING | 2 | SN: 17626- |
|||
| ? | SD3040-12100X0 | • PLATE | 1 | SN: 17626- |
|||
| ? | SD1320-07800X0 | • ARMATURE ASS'Y | 1 | SN: 17626- |
|||
| ? | SD6206-01110X0 | • • BEARING,BALL | 1 | SN: 17626- |
|||
| ? | SD6206-01120X0 | • • BEARING,BALL | 1 | SN: 17626- |
|||
| ? | SD5010-27421X0 | • BOLT | 2 | SN: 17626- |
|||
| ? | SD2245-00830X0 | • CASE,GEAR | 1 | SN: 17626- |
|||
| ? | SD5031-05700X0 | • SHIM | 1 | SN: 17626- |
|||
| ? | SD2441-03200X0 | • SHAFT | 1 | SN: 17626- |
|||
| ? | SD2244-06902X0 | • HOLDER,CENTER | 1 | SN: 17626- |
|||
| ? | SD6410-01000X0 | • SEAL,OIL | 1 | SN: 17626- |
|||
| ? | SD6206-01710X0 | • BEARING,BALL | 1 | SN: 17626- |
|||
| ? | SD1361-04800X0 | • PINION CLUTCH ASS'Y | 1 | SN: 17626- |
|||
| ? | SD3661-02000X0 | • STOPPER,PINION | 1 | SN: 17626- |
|||
| ? | SD5221-01200X0 | • HOOK | 2 | SN: 17626- |
|||
| ? | SD5058-04200X0 | • RING,RETAINING | 1 | SN: 17626- |
|||
| ? | SD5010-27430X0 | • BOLT | 1 | SN: 17626- |
|||
| ? | SD4141-26311X0 | • PACKING | 1 | SN: 17626- |
|||
| ? | SD1372-04200X0 | • LEVER ASS'Y | 1 | SN: 17626- |
|||
| ? | SD3600-17800X0 | • ROD | 1 | SN: 17626- |
|||
| ? | SD4223-05200X0 | • HOLDER,LEVER | 2 | SN: 17626- |
|||
| ? | SD5201-10100X0 | • COIL,SPRING | 1 | SN: 17626- |
|||
| ? | SD2407-02101X0 | • COLLAR | 1 | SN: 17626- |
|||
| ? | SD2244-06821X0 | • BRACKET,CENTER | 1 | SN: 17626- |
|||
| ? | SD2046-14100X9 | • CASE ASS'Y,PINION | 1 | SN: 17626- |
|||
| ? | SD2620-10500X9 | • • METAL | 1 | SN: 17626- |
|||
| ? | SD5010-26200X0 | • BOLT | 5 | SN: 17626- |
|||
| ? | SD5010-26220X0 | • BOLT | 1 | SN: 17626- |
|||
| ? | SD1350-10930X9 | • SWITCH ASS'Y,ENGAGE | 1 | SN: 17626- |
|||
| ? | SD5010-27300X0 | • BOLT | 2 | SN: 17626- |
|||
| ? | SD0590-0011751 | • RELAY,SAFETY | 1 | SN: 17626- |
|||
| ? | SD1331-04300X9 | BRUSH HOLDER ASS'Y,(SERVICE PARTS) | 1 | SN: 17626- |
|||
| ? | SD5250-02800X0 | • SPRING,BRUSH | 4 | SN: 17626- |
|||
| ? | SD2660-07400X6 | • BRUSH,(FOR 1ST SERVICE ONLY) | 1 | SN: 17626- |
|||
| ? | SD2660-07400X7 | • • BRUSH,(FROM 2ND SERVICE) | 4 | SN: 17626- |
