| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6137-72-1190 | INJECTION PUMP ASS'Y | 1 | SN: 86477- |
|||
| ? | 6137-72-1111 | INJECTION PUMP ASS'Y | 1 | SN: 84313-86476 |
|||
| ? | DK101060-2470 | • PUMP ASS'Y | 1 | SN: 84313- |
|||
| ? | DK131071-6220 | • • HOUSING | 1 | SN: 84313- |
|||
| ? | DK029040-6020 | • • • STUD | 3 | SN: 84313- |
|||
| ? | DK131400-0100 | • • • ADAPTER | 1 | SN: 84313- |
|||
| ? | DK131420-0420 | • • • BOLT | 1 | SN: 84313- |
|||
| ? | DK131028-6020 | • • COVER | 1 | SN: 84313- |
|||
| ? | DK131011-0800 | • • • GASKET | 1 | SN: 84313- |
|||
| ? | DK131017-1000 | • • SCREW | 2 | SN: 84313- |
|||
| ? | DK029340-6020 | • • GASKET | 2 | SN: 84313- |
|||
| ? | DK131034-1401 | • • PLUG | 6 | SN: 84313- |
|||
| ? | DK139206-0400 | • • NUT | 3 | SN: 84313- |
|||
| ? | DK029633-1010 | • • O-RING | 1 | SN: 84313- |
|||
| ? | DK131151-5820 | • • PLUNGER ASS'Y | 6 | SN: 84313- |
|||
| ? | DK131110-7720 | • • VALVE,DELIVERY | 6 | SN: 84313- |
|||
| ? | DK131112-1600 | • • SPRING | 6 | SN: 84313- |
|||
| ? | DK131115-1600 | • • GASKET | 6 | SN: 84313- |
|||
| ? | DK131116-7600 | • • HOLDER | 6 | SN: 84313- |
|||
| ? | DK131117-2300 | • • STOPPER | 6 | SN: 84313- |
|||
| ? | DK131122-0520 | • • PLATE ASS'Y | 3 | SN: 84313- |
|||
| ? | DK029632-0030 | • • O-RING | 6 | SN: 84313- |
|||
| ? | DK131200-0620 | • • TAPPET ASS'Y | 6 | SN: 84313- |
|||
| ? | DK131201-0100 | • • • NUT | 1 | SN: 84313- |
|||
| ? | DK131202-0100 | • • • BOLT,TAPPET | 1 | SN: 84313- |
|||
| ? | DK131203-0200 | • • • PIN | 1 | SN: 84313- |
|||
| ? | DK131204-1000 | • • • ROLLER | 1 | SN: 84313- |
|||
| ? | DK131205-0500 | • • • BUSHING | 1 | SN: 84313- |
|||
| ? | DK131206-0200 | • • • GUIDE | 1 | SN: 84313- |
|||
| ? | DK131215-2400 | • • SPRING,PLUNGER | 6 | SN: 84313- |
|||
| ? | DK131216-0100 | • • SEAT,SPRING | 6 | SN: 84313- |
|||
| ? | DK131217-0100 | • • SEAT,SPRING | 6 | SN: 84313- |
|||
| ? | DK131256-0000 | • • RACK,CONTROL | 1 | SN: 84313- |
|||
| ? | DK131226-0300 | • • SCREW | 1 | SN: 84313- |
|||
| ? | DK131240-0100 | • • PINION | 6 | SN: 84313- |
|||
| ? | DK131241-0100 | • • SLEEVE,CONTROL | 6 | SN: 84313- |
|||
| ? | DK131242-0100 | • • SCREW | 6 | SN: 84313- |
|||
| ? | DK131370-1400 | • • CAMSHAFT | 1 | SN: 84313- |
|||
| ? | DK016630-2030 | • • BEARING | A/R | SN: 84313- |
|||
| ? | DK028201-7020 | • • BEARING | A/R | SN: 84313- |
|||
| ? | DK131302-0300 | • • RING | 2 | SN: 84313- |
|||
| ? | DK029311-7010 | • • SHIM¤ 0.1MM | A/R | SN: 84313- |
|||
| ? | DK029311-7020 | • • SHIM¤ 0.12MM | A/R | SN: 84313- |
|||
| ? | DK029311-7030 | • • SHIM¤ 0.14MM | A/R | SN: 84313- |
|||
| ? | DK029311-7040 | • • SHIM¤ 0.16MM | A/R | SN: 84313- |
|||
| ? | DK029311-7050 | • • SHIM¤ 0.18MM | A/R | SN: 84313- |
|||
| ? | DK029311-7090 | • • SHIM¤ 0.3MM | A/R | SN: 84313- |
|||
| ? | DK029311-7060 | • • SHIM¤ 0.5MM | A/R | SN: 84313- |
|||
| ? | DK029311-7210 | • • SHIM¤ 0.7MM | A/R | SN: 84313- |
|||
| ? | DK029311-7070 | • • SHIM¤ 1.0MM | A/R | SN: 84313- |
|||
| ? | DK029311-7220 | • • SHIM¤ 1.4MM | A/R | SN: 84313- |
|||
| ? | DK139417-0000 | • • SHIM¤ 2.40MM | A/R | SN: 84313- |
|||
| ? | DK131306-0800 | • • BEARING,CENTER | 1 | SN: 84313- |
|||
| ? | DK029050-5010 | • • SCREW | 2 | SN: 84313- |
|||
| ? | DK026505-0940 | • • GASKET | 2 | SN: 84313- |
|||
| ? | DK029621-7050 | • • SEAL,OIL | 1 | SN: 84313- |
|||
| ? | DK131330-2600 | • • COVER | 1 | SN: 84313- |
|||
| ? | DK020006-1440 | • • BOLT | 4 | SN: 84313- |
|||
| ? | DK029634-4020 | • • O-RING | 1 | SN: 84313- |
|||
| ? | DK156635-4000 | • • COUPLING | 1 | SN: 84313- |
|||
| ? | DK131325-0500 | • • NUT | 1 | SN: 84313- |
|||
| ? | DK023641-2410 | • • WASHER,SPRING | 1 | SN: 84313- |
|||
| ? | DK025803-1610 | • • KEY¤ 16MM,WOODRUFF | 1 | SN: 84313- |
|||
| ? | DK029731-4680 | • • BOLT,EYE | 1 | SN: 84313- |
|||
| ? | DK029341-4130 | • • GASKET | 2 | SN: 84313- |
|||
| ? | DK029731-0120 | • • BOLT,EYE | 1 | SN: 84313- |
|||
| ? | DK029341-0110 | • • GASKET | 2 | SN: 84313- |
