| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6137-72-1190) | INJECTION PUMP ASS'Y | 1 | SN: 86477- |
|||
| ? | (6137-72-1111) | INJECTION PUMP ASS'Y | 1 | SN: 84313-86476 |
|||
| ? | (6137-72-1170) | INJECTION PUMP ASS'Y,(TUNNEL SPEC.) | 1 | SN: 84313- |
|||
| ? | 6136-21-6110 | BRACKET | 1 | SN: 84313- |
|||
| ? | 01010-31035 | BOLT | 4 | SN: 84313- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 84313- |
|||
| ? | 01010-30870 | BOLT | 4 | SN: 84313- |
|||
| ? | 01602-00825 | WASHER,SPRING | 4 | SN: 84313- |
|||
| ? | 6110-71-5810 | WASHER | 4 | SN: 84313- |
|||
| ? | 6136-71-3320 | COVER | 1 | SN: 84313- |
|||
| ? | 07012-00032 | SEAL,OIL (K2) | 1 | SN: 84313- |
|||
| ? | 6136-71-3250 | SHAFT | 1 | SN: 84313- |
|||
| ? | 04010-00416 | KEY | 1 | SN: 84313- |
|||
| ? | 6131-81-3141 | GASKET (K2) | 1 | SN: 84313- |
|||
| ? | 01050-31025 | BOLT | 4 | SN: 84313- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 84313- |
|||
| ? | 6136-71-3120 | GEAR,INJECTION | 1 | SN: 84313- |
|||
| ? | 04000-00722 | KEY | 1 | SN: 84313- |
|||
| ? | 06000-06007 | BEARING,BALL | 2 | SN: 84313- |
|||
| ? | 6136-71-3130 | NUT,LOCK | 1 | SN: 84313- |
|||
| ? | 6136-71-3141 | WASHER,LOCK (K2) | 1 | SN: 84313- |
|||
| ? | 6136-81-3951 | SHAFT | 1 | SN: 84313- |
|||
| ? | 6136-71-5110 | PIPE,INJECTION¤ NO.1 | 1 | SN: 84313- |
|||
| ? | 6136-71-5120 | PIPE,INJECTION¤ NO.2 | 1 | SN: 84313- |
|||
| ? | 6136-71-5130 | PIPE,INJECTION¤ NO.3 | 1 | SN: 84313- |
|||
| ? | 6136-71-5140 | PIPE,INJECTION¤ NO.4 | 1 | SN: 84313- |
|||
| ? | 6136-71-5150 | PIPE,INJECTION¤ NO.5 | 1 | SN: 84313- |
|||
| ? | 6136-71-5160 | PIPE,INJECTION¤ NO.6 | 1 | SN: 84313- |
|||
| ? | 6144-71-5720 | CLIP ASS'Y | 9 | SN: 84313- |
|||
| ? | 6144-71-5730 | • CLIP | 1 | SN: 84313- |
|||
| ? | 6144-71-5740 | • CLIP¤ WITH THREAD | 1 | SN: 84313- |
|||
| ? | 6130-71-5750 | • BOLT | 1 | SN: 84313- |
|||
| ? | 01601-20513 | • WASHER,SPRING | 1 | SN: 84313- |
|||
| ? | 6136-71-5730 | BRACKET | 1 | SN: 84313- |
|||
| ? | 01010-31020 | BOLT | 1 | SN: 84313- |
|||
| ? | 01642-01016 | WASHER | 1 | SN: 84313- |
|||
| ? | 6136-71-5720 | CLIP | 1 | SN: 84313- |
|||
| ? | 01010-31025 | BOLT | 1 | SN: 84313- |
|||
| ? | 01580-01008 | NUT | 1 | SN: 84313- |
|||
| ? | 01642-01016 | WASHER | 2 | SN: 84313- |
|||
| ? | 6136-71-5720 | CLIP | 1 | SN: 84313- |
|||
| ? | 6631-11-6390 | SPACER | 1 | SN: 84313- |
|||
| ? | 01010-31030 | BOLT | 1 | SN: 84313- |
|||
| ? | 01642-01016 | WASHER | 1 | SN: 84313- |
|||
| ? | 6136-51-6740 | PIPE,INLET | 1 | SN: 84313- |
|||
| ? | 07206-10610 | BOLT,JOINT | 1 | SN: 84313- |
|||
| ? | 07005-01012 | GASKET (K2) | 2 | SN: 84313- |
|||
| ? | 6136-51-6780 | PIPE,OUTLET | 1 | SN: 84313- |
|||
| ? | (☒6136-51-6720) | PIPE,OUTLET | 1 | SN: (84313-101761) |
|||
| ? | 07206-10812 | BOLT,JOINT | 1 | SN: 84313- |
|||
| ? | 07005-01212 | GASKET (K2) | 2 | SN: 84313- |
