| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-813-7111 | STARTING MOTOR ASS'Y,(7.5KW) | 1 | SN: 60863-83598 |
|||
| ? | KD0-23100-0230 | • ARMATURE ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD1-0456-62047 | • • BEARING,BALL | 1 | SN: 60863-83598 |
|||
| ? | KD1-0456-62007 | • • BEARING,BALL | 1 | SN: 60863-83598 |
|||
| ? | KD0-23230-0150 | • FIELD COIL ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD7-23780-0070 | • TERMINAL ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD0-23300-0270 | • FRONT BRACKET ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD7-23351-0080 | • • METAL | 1 | SN: 60863-83598 |
|||
| ? | KD7-23120-0090 | • SHAFT ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD1-0456-60067 | • • BEARING,BALL | 1 | SN: 60863-83598 |
|||
| ? | KD1-23181-0020 | • STOPPER,PINION | 1 | SN: 60863-83598 |
|||
| ? | KD1-23914-0020 | • RING,CLIP | 1 | SN: 60863-83598 |
|||
| ? | KD1-23500-0160 | • CLUTCH ASS'Y,OVER RUNNING | 1 | SN: 60863-83598 |
|||
| ? | KD1-23600-0080 | • CENTER BRACKET A. | 1 | SN: 60863-83598 |
|||
| ? | KD1-23611-0080 | • BRACKET,CENTER | 1 | SN: 60863-83598 |
|||
| ? | KD1-23320-0190 | • SHIFT LEVER ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD0-47100-3420 | • MAGNETIC SWITCH A. | 1 | SN: 60863-83598 |
|||
| ? | KD0-23711-0221 | • BRACKET,REAR | 1 | SN: 60863-83598 |
|||
| ? | KD1-23913-0040 | • SPRING,BRUSH | 4 | SN: 60863-83598 |
|||
| ? | KD0-23750-0050 | • BRUSH HOLDER ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD1-23740-0050 | • BRUSH ASS'Y | 4 | SN: 60863-83598 |
|||
| ? | KD1-25922-2800 | • PLATE | 4 | SN: 60863-83598 |
|||
| ? | KD0-09001-4380 | • BOLT,THROUGH | 2 | SN: 60863-83598 |
|||
| ? | KD0-25000-7510 | • SWITCH ASS'Y | 1 | SN: 60863-83598 |
|||
| ? | KD7-23920-0320 | WASHER ASS'Y,(NOT SHOWN) | 1 | SN: 60863-83598 |
|||
| ? | KD7-09210-1000 | SEAL ASS'Y,(NOT SHOWN) | 1 | SN: 60863-83598 |
