| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-821-7420 | ALTERNATOR A. (35A) | 1 | SN: 71931- |
|||
| ? | □600-821-8680 | ALTERNATOR A. (35A) | 1 | SN: 60863-71930 |
|||
| ? | KD1-33100-1270 | • ROTOR ASS'Y | 1 | SN: 60863- |
|||
| ? | KD1-0456-63057 | • BEARING,BALL | 1 | SN: 60863- |
|||
| ? | KD1-0416-04160 | • KEY | 1 | SN: 60863- |
|||
| ? | KD1-33923-0780 | • COLLAR | 1 | SN: 60863- |
|||
| ? | KD1-0055-06162 | • SCREW | 3 | SN: 60863- |
|||
| ? | KD0-35926-0060 | • RETAINER | 1 | SN: 60863- |
|||
| ? | KD1-33951-0610 | • PACKING | 2 | SN: 60863- |
|||
| ? | KD1-33926-0750 | • RETAINER | 1 | SN: 60863- |
|||
| ? | KD1-33926-0730 | • RETAINER | 1 | SN: 60863- |
|||
| ? | KD1-33923-0810 | • COLLAR | 1 | SN: 60863- |
|||
| ? | KD1-33926-0770 | • RETAINER | 1 | SN: 60863- |
|||
| ? | KD1-33200-1230 | • STATOR ASS'Y | 1 | SN: 60863- |
|||
| ? | KD1-33310-1060 | • BRACKET,FRONT | 1 | SN: 60863- |
|||
| ? | KD0-0275-06852 | • BOLT | 3 | SN: 60863- |
|||
| ? | KD1-35411-0360 | • PULLEY,NON HARDENING | 1 | SN: 71931- |
|||
| ? | KD1-35411-0020 | • PULLEY,NON HARDENING | 1 | SN: 60863-71930 |
|||
| ? | KD1-33421-0510 | • FAN | 1 | SN: 60863- |
|||
| ? | KD1-0330-16022 | • WASHER | 1 | SN: 60863- |
|||
| ? | KD1-0335-16602 | • WASHER,SPRING | 1 | SN: 60863- |
|||
| ? | KD1-09006-0210 | • NUT | 1 | SN: 60863- |
|||
| ? | KD0-33120-0220 | • FIELD COIL ASS'Y | 1 | SN: 60863- |
|||
| ? | KD0-35700-0030 | • REAR BRACKET ASS'Y | 1 | SN: 60863- |
|||
| ? | KD0-33710-2870 | • • REAR BRACKET ASS'Y | 1 | SN: 60863- |
|||
| ? | KD0-33730-2190 | • • RECTIFIER ASS'Y | 1 | SN: 60863- |
|||
| ? | KD0-0080-05102 | • • BOLT | 1 | SN: 60863- |
|||
| ? | KD1-09202-0070 | • • BEARING,ROLLER | 1 | SN: 60863- |
|||
| ? | KD1-33943-0770 | • • BUSHING,INSULATE | 2 | SN: 60863- |
|||
| ? | KD1-33928-0220 | • • STOPPER | 1 | SN: 60863- |
|||
| ? | KD1-09102-0010 | • • PLATE,INSULATE | 1 | SN: 60863- |
|||
| ? | KD0-0055-05252 | • • SCREW | 1 | SN: 60863- |
|||
| ? | KD1-33928-0230 | • • STOPPER | 1 | SN: 60863- |
|||
| ? | KD1-33943-0760 | • • BUSHING,INSULATE | 1 | SN: 60863- |
|||
| ? | KD0-0080-05502 | • • BOLT | 1 | SN: 60863- |
|||
| ? | KD0-0080-05452 | • • BOLT | 1 | SN: 60863- |
|||
| ? | KD1-0550-05013 | • • PLATE,TERMINAL | 1 | SN: 60863- |
|||
| ? | KD7-44000-0907 | • • REGULATOR ASS'Y | 1 | SN: 60863- |
|||
| ? | KD0-0056-05452 | • SCREW | 3 | SN: 60863- |
|||
| ? | KD0-33120-0220 | • FIELD COIL ASS'Y | 1 | SN: 60863- |
