| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 201-70-00940 | BOOM ASS'Y | 1 | SN: 48844-52373 |
|||
| ? | 201-70-00920 | BOOM ASS'Y | 1 | SN: 48712-48843 |
|||
| ? | 201-70-00620 | BOOM ASS'Y | 1 | SN: 45001-48711 |
|||
| ? | ☆ | • BOOM | 1 | SN: 48844-52373 |
|||
| ? | ☆ | • BOOM | 1 | SN: 48712-48843 |
|||
| ? | ☆ | • BOOM | 1 | SN: 45001-48711 |
|||
| ? | 201-70-71XE1 | • • BRACKET (WELDED) | 1 | SN: 48844-@ |
|||
| ? | 201-70-71XA0 | • • BRACKET (WELDED) | 1 | SN: 45001-48843 |
|||
| ? | ☆ | • • • BRACKET (WELDED) | 1 | SN: 48844-@ |
|||
| ? | ☆ | • • • BRACKET (WELDED) | 1 | SN: 45001-48843 |
|||
| ? | 203-46-41130 | • • • SEAT (WELDED) | 2 | SN: 45001-@ |
|||
| ? | 201-70-71230 | • BUSHING | 2 | SN: 45001-@ |
|||
| ? | 07145-00065 | • SEAL,DUST | 2 | SN: 45001-@ |
|||
| ? | 07145-00065 | SEAL,DUST | 2 | SN: 45001-@ |
|||
| ? | 201-06-71280 | WORK LAMP ASS'Y,70W | 1 | SN: 45001-@ |
|||
| ? | 203-06-56410 | BRACKET | 1 | SN: 45001-@ |
|||
| ? | 01010-51225 | BOLT | 1 | SN: 45001-@ |
|||
| ? | 01643-31232 | WASHER | 1 | SN: 45001-@ |
|||
| ? | 201-06-61360 | WIRE | 1 | SN: 45001-@ |
|||
| ? | 203-06-56570 | BAND | 8 | SN: 45001-@ |
|||
| ? | 201-70-71610 | PIN | 1 | SN: 48844-@ |
|||
| ? | 201-70-71261 | PIN | 1 | SN: 45001-48843 |
|||
| ? | 203-46-56270 | PLATE | 1 | SN: 45001-@ |
|||
| ? | 01010-51230 | BOLT | 2 | SN: 45001-@ |
|||
| ? | 01643-31232 | WASHER | 2 | SN: 45001-@ |
|||
| ? | 203-70-24150 | SPACER ? 1.0MM | 1 | SN: 45001-@ |
|||
| ? | 201-70-71270 | SHAFT | 1 | SN: 45001-@ |
|||
| ? | 203-46-56270 | PLATE | 1 | SN: 45001-@ |
|||
| ? | 01010-51230 | BOLT | 2 | SN: 45001-@ |
|||
| ? | 01643-31232 | WASHER | 2 | SN: 45001-@ |
|||
| ? | 202-70-11640 | SPACER ? 1.0MM | 1 | SN: 45001-@ |
|||
| ? | 203-70-34260 | SPACER ? 0.5MM | 1 | SN: 45001-@ |
|||
| ? | 201-70-71250 | PIN | 1 | SN: 45001-@ |
|||
| ? | 04082-00212 | LOCK | 1 | SN: 45001-@ |
|||
| ? | 01010-51230 | BOLT | 2 | SN: 45001-@ |
|||
| ? | 01643-31232 | WASHER | 2 | SN: 45001-@ |
|||
| ? | 201-70-71280 | SPACER ? 1.0MM | 1 | SN: 45001-@ |
|||
| ? | 201-62-71420 | HOSE | 1 | SN: 48712-@ |
|||
| ? | 201-62-71420 | HOSE | 2 | SN: 45001-48711 |
|||
| ? | 201-62-77110 | HOSE | 1 | SN: 48712-@ |
|||
| ? | 201-62-74110 | TUBE | 1 | SN: 45001-@ |
|||
| ? | 201-62-74121 | TUBE | 1 | SN: 48712-52373 |
|||
| ? | 201-62-74120 | TUBE | 1 | SN: 45001-48711 |
|||
| ? | 201-62-74130 | TUBE | 1 | SN: 45001-@ |
|||
| ? | 201-62-74140 | TUBE | 1 | SN: 45001-@ |
|||
| ? | 203-70-53380 | CLAMP | 3 | SN: 48712-52373 |
|||
| ? | 203-70-53380 | CLAMP | 6 | SN: 45001-48711 |
|||
| ? | 201-973-7430 | CLAMP | 3 | SN: 48712-52373 |
|||
| ? | 203-70-53390 | CLAMP | 4 | SN: 45001-@ |
|||
| ? | 01010-51025 | BOLT | 20 | SN: 45001-52373 |
|||
| ? | 01643-31032 | WASHER | 20 | SN: 45001-52373 |
|||
| ? | (☉201-63-X2302) | CYLINDER GROUP,BOOM (SEE FIG.Y1620-01A0) | 1 | SN: 45001-52373 |
|||
| ? | (☉201-63-X2313) | CYLINDER GROUP,ARM (SEE FIG.Y1620-11A0) | 1 | SN: 48712-52373 |
|||
| ? | (☉201-63-X2312) | CYLINDER GROUP,ARM (SEE FIG.Y1620-11A0) | 1 | SN: 45001-48711 |
