| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (714-23-10001) | TRANSMISSION ASS'Y | 1 | SN: 51012- KIT-FLAG: _- SERIALNO: 51012- |
|||
| ? | (714-23-10000) | TRANSMISSION ASS'Y | 1 | SN: 50001-51011 KIT-FLAG: _- SERIALNO: 50001-51011 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F5350-51A0 TO F5350-70A0. | SERIALNO: |
|||||
| ? | 714-23-12033 | • CLUTCH ASS'Y,2ND AND 3RD | 1 | SN: 51012- KIT-FLAG: _- SERIALNO: 51012- |
|||
| ? | 714-23-12032 | • CLUTCH ASS'Y,2ND AND 3RD | 1 | SN: 50001-51011 KIT-FLAG: _- SERIALNO: 50001-51011 |
|||
| ? | 714-23-12133 | • • SHAFT AND CYLINDER A,2ND AND 3RD | 1 | SN: 51012- KIT-FLAG: _- SERIALNO: 51012- |
|||
| ? | 714-23-12132 | • • SHAFT AND CYLINDER A,2ND AND 3RD | 1 | SN: 50001-51011 KIT-FLAG: _- SERIALNO: 50001-51011 |
|||
| ? | ☆ | • • • SHAFT,LOWER | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-11-19390 | • • • BALL | 2 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-08-12950 | • • • ORIFICE | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | ☆ | • • • HOUSING,2ND | 1 | SN: 51012- KIT-FLAG: _- SERIALNO: 51012- |
|||
| ? | ☆ | • • • HOUSING,2ND | 1 | SN: 50001-51011 KIT-FLAG: _- SERIALNO: 50001-51011 |
|||
| ? | 714-23-12690 | • • PISTON,RANGE | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-23-12660 | • • PISTON | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 419-15-12140 | • • RING,SNAP | 2 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-12-19711 | • • DISC | 21 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-16-19730 | • • PLATE,SEPARATE | 23 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 56D-15-12710 | • • SPRING,WAVE | 21 | SN: 51012- KIT-FLAG: _- SERIALNO: 51012- |
|||
| ? | □419-15-12133 | • • SPRING,WAVE | 21 | SN: 50001-51011 KIT-FLAG: _- SERIALNO: 50001-51011 |
|||
| ? | 714-12-12610 | • • PLATE,END | 2 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-16-19220 | • • RING | 2 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-07-19320 | • • RING,SEAL (K1) | 2 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-08-19570 | • • WASHER,THRUST | 4 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-23-19430 | • • BEARING,NEEDLE | 4 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-23-12710 | • • SPACER,4TH | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 06040-06313 | • • BEARING | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-12-19340 | • • BEARING,ROLLER | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-23-12451 | • • GEAR,2ND | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-23-12540 | • • GEAR,LOWER, OUTPUT | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-12-19520 | • • RING,SNAP | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 714-23-12460 | • • GEAR,3RD, 55 TEETH AND 41 TEETH | 1 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
|||
| ? | 419-15-12122 | • RING | 3 | SN: 50001- KIT-FLAG: _- SERIALNO: 50001- |
