| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 23A-03-11900 | RADIATOR ASS'Y | 1 | SN: 15001-15089 |
|||
| ? | 23A-03-11910 | • CORE ASS'Y | 1 | SN: 15001-15089 |
|||
| ? | 23D-03-11320 | • SHROUD | 1 | SN: 15001-15089 |
|||
| ? | 23E-03-11130 | • WIRE,NET | 1 | SN: 15001-15089 |
|||
| ? | 23D-03-11340 | • CLIP | 2 | SN: 15001-15089 |
|||
| ? | 01010-50616 | • BOLT | 8 | SN: 15001-15089 |
|||
| ? | 01643-30623 | • WASHER | 8 | SN: 15001-15089 |
|||
| ? | 01010-51020 | • BOLT | 4 | SN: 15001-15089 |
|||
| ? | 01643-31032 | • WASHER | 8 | SN: 15001-15089 |
|||
| ? | 6140-61-6510 | • VALVE,DRAIN | 1 | SN: 15001-15089 |
|||
| ? | 236-03-21150 | • PIPE,DRAIN | 1 | SN: 15001-15089 |
|||
| ? | 101-03-13141 | • CAP | 1 | SN: 15001-15089 |
|||
| ? | 230-03-11470 | • STRAINER | 1 | SN: 15001-15089 |
|||
| ? | 23D-03-11330 | • PIPE,OVER FLOW | 1 | SN: 15001-15089 |
|||
| ? | 23B-03-11520 | CUSHION | 4 | SN: 15001-15089 |
|||
| ? | 236-03-21190 | WASHER | 2 | SN: 15001-@ |
|||
| ? | 01012-51480 | BOLT | 2 | SN: 15001-@ |
|||
| ? | 01590-11416 | NUT | 2 | SN: 15001-@ |
|||
| ? | 01640-21426 | WASHER | 2 | SN: 15001-15089 |
|||
| ? | 04050-13028 | PIN,COTTER | 2 | SN: 15001-@ |
|||
| ? | 04248-31646 | ROD | 2 | SN: 15001-15089 |
|||
| ? | 04221-21688 | YOKE,L.H. THREAD | 2 | SN: 15001-15089 |
|||
| ? | 01508-21610 | NUT,L.H. THREAD | 2 | SN: 15001-15089 |
|||
| ? | 04211-21688 | YOKE | 2 | SN: 15001-15089 |
|||
| ? | 01582-11613 | NUT | 2 | SN: 15001-15089 |
|||
| ? | 04205-11645 | PIN | 4 | SN: 15001-15089 |
|||
| ? | 01641-21626 | WASHER | 4 | SN: 15001-15089 |
|||
| ? | 04050-14025 | PIN,COTTER | 4 | SN: 15001-15089 |
