| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 262-22-00011 | FINAL DRIVE ASS'Y | 1 | SN: 10001-@ |
|||
| ? | (☒262-22-00010) | FINAL DRIVE ASS'Y | 1 | SN: (10001-10024) |
|||
| ? | 23B-22-11110 | • CASE | 1 | SN: 10001-@ |
|||
| ? | 23A-22-11570 | • PLATE | 1 | SN: 10001-@ |
|||
| ? | 23A-22-11650 | • GASKET (K2) | 1 | SN: 10001-@ |
|||
| ? | 01010-51235 | • BOLT | 2 | SN: 10001-@ |
|||
| ? | 01643-31232 | • WASHER | 2 | SN: 10001-@ |
|||
| ? | 23B-22-21110 | • CASE,SIDE | 2 | SN: 10001-@ |
|||
| ? | 23B-22-21190 | • BUSHING | 4 | SN: 10001-@ |
|||
| ? | 07000-15315 | • O-RING (K2) | 2 | SN: 10001-@ |
|||
| ? | 01010-51660 | • BOLT | 44 | SN: 10001-@ |
|||
| ? | 01643-31645 | • WASHER | 44 | SN: 10001-@ |
|||
| ? | 23B-22-21120 | • FLANGE | 2 | SN: 10001-@ |
|||
| ? | 23A-22-11510 | • TUBE | 2 | SN: 10001-@ |
|||
| ? | 23B-22-21130 | • O-RING (K2) | 2 | SN: 10001-@ |
|||
| ? | 07000-15370 | • O-RING (K2) | 2 | SN: 10001-@ |
|||
| ? | 23B-22-21210 | • WASHER | 8 | SN: 10001-@ |
|||
| ? | 23B-22-21201 | • CAGE ASS'Y | 2 | SN: 10001-@ |
|||
| ? | (☒23B-22-21200) | • CAGE ASS'Y | 2 | SN: (10001-10024) |
|||
| ? | ☆ | • • CAGE | 2 | SN: 10001-10024 |
|||
| ? | ☆ | • • PIN,DOWEL | 2 | SN: 10001-@ |
|||
| ? | 23B-22-21280 | • O-RING (K2) | 2 | SN: 10001-@ |
|||
| ? | 01010-51280 | • BOLT | 8 | SN: 10001-@ |
|||
| ? | 23B-22-11820 | • BOLT | 4 | SN: 10001-@ |
|||
| ? | 01580-11210 | • NUT | 12 | SN: 10001-@ |
|||
| ? | 01643-31232 | • WASHER | 12 | SN: 10001-@ |
|||
| ? | 01010-51225 | • BOLT | 8 | SN: 10001-@ |
|||
| ? | 01010-51665 | • BOLT | 34 | SN: 10001-@ |
|||
| ? | 01643-31645 | • WASHER | 34 | SN: 10001-@ |
