| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 262-60-58150 | HOSE | 1 | SN: 10001- |
|||
| ? | 262-60-58160 | HOSE | 1 | SN: 10001- |
|||
| ? | 07000-13038 | O-RING | 4 | SN: 10001- |
|||
| ? | 07371-51260 | FLANGE | 8 | SN: 10001- |
|||
| ? | 01010-51245 | BOLT | 16 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 16 | SN: 10001- |
|||
| ? | 07236-51034 | ELBOW | 1 | SN: 10001- |
|||
| ? | 07002-13334 | O-RING | 1 | SN: 10001- |
|||
| ? | 07042-20108 | PLUG | 1 | SN: 10001- |
|||
| ? | 07113-01014 | HOSE | 1 | SN: 10009- |
|||
| ? | □07103-51014 | HOSE | 1 | SN: 10001-10008 |
|||
| ? | 07103-51015 | HOSE | 1 | SN: 10001- |
|||
| ? | 07230-21034 | UNION | 2 | SN: 10001- |
|||
| ? | 262-60-58260 | UNION | 1 | SN: 10001- |
|||
| ? | 07002-13334 | O-RING | 3 | SN: 10001- |
|||
| ? | 262-60-54561 | MANIFOLD | 1 | SN: 10001- |
|||
| ? | 262-60-54570 | BRACKET | 2 | SN: 10001- |
|||
| ? | 01010-51225 | BOLT | 8 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 8 | SN: 10001- |
|||
| ? | 01010-51225 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 10001- |
|||
| ? | 262-814-7121 | VALVE | 1 | SN: 10021- |
|||
| ? | □262-814-7120 | VALVE | 1 | SN: 10001-10020 |
|||
| ? | 01010-50895 | BOLT | 6 | SN: 10001- |
|||
| ? | 01643-30823 | WASHER | 6 | SN: 10001- |
|||
| ? | 262-60-58580 | ELBOW | 2 | SN: 10001- |
|||
| ? | 07002-11423 | O-RING | 2 | SN: 10001- |
|||
| ? | 262-60-58930 | DAMPER | 2 | SN: 10001- |
|||
| ? | 262-60-58590 | JOINT | 2 | SN: 10001- |
|||
| ? | 262-06-15180 | GASKET | 4 | SN: 10001- |
|||
| ? | 07082-00217 | HOSE | 1 | SN: 10001- |
|||
| ? | 07082-00217 | HOSE | 1 | SN: 10001- |
|||
| ? | 22X-75-17120 | PLUG | 2 | SN: 10001- |
|||
| ? | 07002-13334 | O-RING | 2 | SN: 10001- |
|||
| ? | 07040-11812 | PLUG | 1 | SN: 10001- |
|||
| ? | 07002-11823 | O-RING | 1 | SN: 10001- |
|||
| ? | 08036-01814 | CLIP | 2 | SN: 10001- |
|||
| ? | 01010-51020 | BOLT | 1 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 10001- |
