| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 262-60-53111 | TANK | 1 | SN: 10001- |
|||
| ? | 07230-20522 | UNION | 1 | SN: 10001- |
|||
| ? | 07002-12434 | O-RING | 1 | SN: 10001- |
|||
| ? | 262-60-58541 | TEE | 1 | SN: 10001- |
|||
| ? | 07222-00515 | PLUG | 1 | SN: 10001- |
|||
| ? | 07221-20522 | NUT,SLEEVE | 1 | SN: 10001- |
|||
| ? | 07030-10252 | BREATHER | 1 | SN: 10001- |
|||
| ? | 23A-60-13500 | GAUGE | 1 | SN: 10001- |
|||
| ? | 07005-01012 | GASKET | 4 | SN: 10001- |
|||
| ? | 07051-20000 | CAP | 1 | SN: 10001- |
|||
| ? | 07051-00003 | • GASKET | 1 | SN: 10001- |
|||
| ? | 07056-10045 | STRAINER | 1 | SN: 10001- |
|||
| ? | (262-60-22100) | FILTER ASS'Y,(SEE FIG.6015) | 3 | SN: 10001- |
|||
| ? | (234-60-31300) | FILTER ASS'Y,(SEE FIG.6011) | 1 | SN: 10001- |
|||
| ? | 273-60-13250 | GASKET | 4 | SN: 10001- |
|||
| ? | 01010-51030 | BOLT | 16 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 16 | SN: 10001- |
|||
| ? | 01010-51635 | BOLT | 4 | SN: 10001- |
|||
| ? | 01643-31645 | WASHER | 4 | SN: 10001- |
|||
| ? | 262-60-53123 | BRACKET | 1 | SN: 10001- |
|||
| ? | 01010-52065 | BOLT | 4 | SN: 10001- |
|||
| ? | 01580-12016 | NUT | 4 | SN: 10001- |
|||
| ? | 01643-32060 | WASHER | 8 | SN: 10001- |
|||
| ? | 262-60-53132 | COVER | 1 | SN: 10001- |
|||
| ? | 262-54-55760 | FELT | 1 | SN: 10001- |
|||
| ? | 04431-30000 | PLATE | 10 | SN: 10001- |
|||
| ? | 01010-51020 | BOLT | 9 | SN: 10001- |
|||
| ? | 01643-31032 | WASHER | 9 | SN: 10001- |
