| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6201-12-1010 | CYLINDER HEAD ASS'Y,WITH VALVE | 1 | SN: 10001- |
|||
| ? | 6201-12-1100 | • CYLINDER HEAD ASS'Y,VALVE LESS | 1 | SN: 10001- |
|||
| ? | ☆ | • • HEAD,CYLINDER | 1 | SN: 10001- |
|||
| ? | 6204-19-1310 | • • GUIDE,VALVE | 6 | SN: 10001- |
|||
| ? | 6207-11-1430 | • • SEAT,INTAKE VALVE (STD) | 3 | SN: 10001- |
|||
| ? | 6207-19-1430 | • • SEAT ? 0.25MM,INTAKE VALVE (OS) | 3 | SN: 10001- |
|||
| ? | 6207-18-1430 | • • SEAT ? 0.50MM,INTAKE VALVE (OS) | 3 | SN: 10001- |
|||
| ? | 6204-11-1440 | • • SEAT,EXHAUST VALVE (STD) | 3 | SN: 10001- |
|||
| ? | 6204-19-1440 | • • SEAT ? 0.25MM,EXHAUST VALVE (OS) | 3 | SN: 10001- |
|||
| ? | 6204-18-1440 | • • SEAT ? 0.50MM,EXHAUST VALVE (OS) | 3 | SN: 10001- |
|||
| ? | 07046-41008 | • • PLUG | 3 | SN: 10001- |
|||
| ? | 07046-41810 | • • PLUG | 4 | SN: 10001- |
|||
| ? | 07046-42216 | • • PLUG | 2 | SN: 10001- |
|||
| ? | 07046-42516 | • • PLUG | 10 | SN: 10001- |
|||
| ? | 02720-40104 | • • PLUG | 1 | SN: 10001- |
|||
| ? | 6201-11-8910 | • • PIPE,BREATHER | 1 | SN: 10001- |
|||
| ? | 6207-41-4110 | • VALVE,INTAKE | 3 | SN: 15705- |
|||
| ? | ♦6204-41-4110 | • VALVE,INTAKE | 3 | SN: 10001-15704 |
|||
| ? | 6204-41-4210 | • VALVE,EXHAUST | 3 | SN: 10001- |
|||
| ? | 6204-41-4510 | • SEAT,SPRING | 6 | SN: 10001- |
|||
| ? | 6204-41-4520 | • COTTER | 12 | SN: 10001- |
|||
| ? | 6204-41-4410 | • SPRING,VALVE | 6 | SN: 10001- |
|||
| ? | 6204-41-4540 | • SEAL,EXHAUST VALVE (K1) | 3 | SN: 10001- |
|||
| ? | 6204-41-4550 | CAP,VALVE STEM | 6 | SN: 14181- |
|||
| ? | 6202-12-2110 | PLUG,HOT | 3 | SN: 10001- |
|||
| ? | 6201-11-1920 | HANGER,FRONT | 1 | SN: 10001- |
|||
| ? | 6201-11-1910 | HANGER,REAR | 1 | SN: 10001- |
|||
| ? | 01435-00816 | BOLT | 4 | SN: 10001- |
|||
| ? | 6201-12-1812 | GASKET,HEAD (K1) | 1 | SN: 18720- |
|||
| ? | □6201-12-1811 | GASKET,HEAD (K1) | 1 | SN: 13754-18719 |
|||
| ? | □6201-12-1810 | GASKET,HEAD (K1) | 1 | SN: 10001-13753 |
|||
| ? | 6204-13-1610 | BOLT,HEAD | 13 | SN: 16300- |
|||
| ? | □6142-11-1611 | BOLT,HEAD | 13 | SN: 10001-16299 |
|||
| ? | 01643-31232 | WASHER | 13 | SN: 15705- |
