| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-7S-00022 | SWING MOTOR ASS'Y | 1 | SN: 18001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.N1220-51A0 AND N1220-52A0. | ||||||
| ? | (★708-7S-11112) | • CASE | 1 | SN: 18001- |
|||
| ? | (★708-7S-11512) | • COVER,END | 1 | SN: 18001- |
|||
| ? | (★708-7S-11120) | • GASKET | 1 | SN: 18001- |
|||
| ? | (★720-68-19610) | • PIN | 3 | SN: 18001- |
|||
| ? | (★01010-31060) | • BOLT | 4 | SN: 18001- |
|||
| ? | (★708-7S-12111) | • SHAFT | 1 | SN: 18001- |
|||
| ? | (★708-7S-12140) | • BEARING | 1 | SN: 18001- |
|||
| ? | (★708-7T-12250) | • BEARING | 1 | SN: 18001- |
|||
| ? | 708-7T-12230 | • SEAL,OIL | 1 | SN: 18001- |
|||
| ? | 04065-04518 | • RING,SNAP | 1 | SN: 18001- |
|||
| ? | (★708-7T-05020) | • SPACER KIT | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 1.6MM | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 1.7MM | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 1.8MM | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 1.9MM | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 2.0MM | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 2.1MM | 1 | SN: 18001- |
|||
| ? | ☆ | • • SPACER ? 2.2MM | 1 | SN: 18001- |
|||
| ? | (★708-7S-13411) | • PLATE,THRUST | 1 | SN: 18001- |
|||
| ? | (★708-7S-13510) | • RETAINER,RETAINER | 1 | SN: 18001- |
|||
| ? | (★708-7S-13520) | • SPRING | 1 | SN: 18001- |
|||
| ? | (★708-7S-13530) | • SPACER | 2 | SN: 18001- |
|||
| ? | (★708-7T-13540) | • PIN | 3 | SN: 18001- |
|||
| ? | (★04065-03212) | • RING,SNAP | 1 | SN: 18001- |
|||
| ? | (★708-7S-13311) | • PISTON SUB ASS'Y | 7 | SN: 18001- |
|||
| ? | (★708-7S-13340) | • RETAINER,SHOE | 1 | SN: 18001- |
|||
| ? | (★708-7S-13110) | • BLOCK,CYLINDER | 1 | SN: 18001- |
|||
| ? | (★708-7S-13230) | • PLATE,VALVE | 1 | SN: 18001- |
|||
| ? | 708-7T-16110 | • VALVE | 2 | SN: 18001- |
|||
| ? | 708-7T-16130 | • SPRING | 2 | SN: 18001- |
|||
| ? | 07040-11812 | • PLUG | 2 | SN: 18001- |
|||
| ? | 07002-11823 | • O-RING | 2 | SN: 18001- |
