| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-7R-00240 | MOTOR ASS'Y | 1 | SN: 1891- |
|||
| ? | 708-7R-00141 | MOTOR ASS'Y | 1 | SN: 1001-1890 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 AND Y1640-02A0. | ||||||
| ? | ☆ | • MOTOR SUB ASS'Y | 1 | SN: 1891- |
|||
| ? | ☆ | • MOTOR SUB ASS'Y | 1 | SN: 1001-1890 |
|||
| ? | (★708-7R-11640) | • • PLATE,SWASH | 1 | SN: 1891- |
|||
| ? | (★708-7R-11621) | • • PLATE,SWASH | 1 | SN: 1001-1890 |
|||
| ? | (★708-7R-11710) | • • WASHER | 1 | SN: 1001- |
|||
| ? | (★708-7R-11720) | • • FILTER | 1 | SN: 1001- |
|||
| ? | (★708-7R-04080) | • • HOUSING SUB ASS'Y | 1 | SN: 1001- |
|||
| ? | ☆ | • • • HOUSING | 1 | SN: 1001- |
|||
| ? | ☆ | • • • PLUG | 3 | SN: 1001- |
|||
| ? | 708-7R-11220 | • • PLUG | 2 | SN: 1001- |
|||
| ? | 07002-11223 | • • O-RING | 2 | SN: 1001- |
|||
| ? | 708-7R-11210 | • • VALVE | 4 | SN: 1001- |
|||
| ? | 722-10-91130 | • • SPRING | 4 | SN: 1001- |
|||
| ? | 709-32-12861 | • • PLUG | 4 | SN: 1001- |
|||
| ? | 07002-11823 | • • O-RING | 4 | SN: 1001- |
|||
| ? | (★431-40-11210) | • • O-RING | 1 | SN: 1001- |
|||
| ? | (★720-68-19610) | • • PIN | 2 | SN: 1001- |
|||
| ? | (★01252-61230) | • • BOLT | 8 | SN: 1001- |
|||
| ? | (★708-7R-12120) | • • SHAFT | 1 | SN: 1001- |
|||
| ? | (★708-7R-12140) | • • BEARING | 1 | SN: 1001- |
|||
| ? | (★708-7R-12150) | • • BEARING | 1 | SN: 1001- |
|||
| ? | 04065-04218 | • • RING,SNAP | 1 | SN: 1001- |
|||
| ? | (★708-7R-13111) | • • BLOCK,CYLINDER | 1 | SN: 1001- |
|||
| ? | (★708-7R-13241) | • • PLATE,VALVE | 1 | SN: 1891- |
|||
| ? | (★708-7R-13240) | • • PLATE,VALVE | 1 | SN: 1001-1890 |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: 1001- |
|||
| ? | (★708-7R-13540) | • • PIN | 3 | SN: 1001- |
|||
| ? | (★708-7R-13530) | • • WASHER | 2 | SN: 1001- |
|||
| ? | (★708-7R-13560) | • • SPRING | 1 | SN: 1001- |
|||
| ? | (★04065-03012) | • • RING | 1 | SN: 1001- |
|||
| ? | (★708-7R-13590) | • • GUIDE,RETAINER | 1 | SN: 1001- |
|||
| ? | (★708-7R-13360) | • • RETAINER,SHOE | 1 | SN: 1891- |
|||
| ? | (★708-7R-13351) | • • RETAINER,SHOE | 1 | SN: 1001-1890 |
|||
| ? | (★708-7R-13320) | • • PISTON SUB ASS'Y | 7 | SN: 1001- |
|||
| ? | (★708-7R-13420) | • • PLATE,THRUST | 1 | SN: 1891- |
|||
| ? | (★708-7R-13410) | • • PLATE,THRUST | 1 | SN: 1001-1890 |
|||
| ? | (★708-7R-13581) | • • SPACER | 1 | SN: 1001-1890 |
|||
| ? | (★708-7R-15131) | • • PLATE | 4 | SN: 1891- |
|||
| ? | (★708-7R-15130) | • • PLATE | 4 | SN: 1001-1890 |
|||
| ? | (★708-7R-15122) | • • DISC | 3 | SN: 1891- |
|||
| ? | (★708-7R-15121) | • • DISC | 3 | SN: 1001-1890 |
|||
| ? | (★708-7R-15180) | • • PISTON,BRAKE | 1 | SN: 1001- |
|||
| ? | (★07000-12115) | • • O-RING | 1 | SN: 1001- |
|||
| ? | (★07000-12095) | • • O-RING | 1 | SN: 1001- |
|||
| ? | (★708-7R-15150) | • • SPRING | 12 | SN: 1001- |
|||
| ? | (★708-7R-15160) | • • RING | 1 | SN: 1001- |
|||
| ? | (★708-7R-15712) | • • PISTON | 1 | SN: 1001- |
|||
| ? | (★708-7R-15722) | • • SPRING | 1 | SN: 1001- |
|||
| ? | 708-7R-03030 | • • VALVE SUB ASS'Y | 1 | SN: 1001- |
|||
| ? | ☆ | • • • VALVE | 1 | SN: 1001- |
|||
| ? | ☆ | • • • FILTER | 1 | SN: 1001- |
|||
| ? | 708-7R-15670 | • • SPRING | 1 | SN: 1001- |
|||
| ? | 706-73-72680 | • • PLUG | 1 | SN: 1001- |
|||
| ? | 07002-11223 | • • O-RING | 1 | SN: 1001- |
