| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (☉22F-63-X2121) | ARM CYLINDER GROUP,(SUMMER GREEN) | 1 | SN: 1001- |
|||
| ? | (☉707-00-XC970) | ARM CYLINDER GROUP,(NATURAL YELLOW) | 1 | SN: 1001- |
|||
| ? | ==================== | ||||||
| ? | 22F-63-02121 | CYLINDER ASS'Y,ARM | 1 | SN: 1001- |
|||
| ? | 22F-63-66141 | • CYLINDER | 1 | SN: 1001- |
|||
| ? | 707-76-40570 | • BUSHING | 1 | SN: 1001- |
|||
| ? | 07145-00040 | • SEAL,DUST (KIT) | 2 | SN: 1001- |
|||
| ? | 707-29-75010 | • HEAD,CYLINDER | 1 | SN: 1001- |
|||
| ? | 07177-04530 | • BUSHING | 1 | SN: 1001- |
|||
| ? | 707-51-45210 | • PACKING,ROD (KIT) | 1 | SN: 1001- |
|||
| ? | 112-63-15370 | • SEAL,DUST (KIT) | 1 | SN: 1001- |
|||
| ? | 07179-12057 | • RING,SNAP | 1 | SN: 1001- |
|||
| ? | 07000-12070 | • O-RING (KIT) | 1 | SN: 1001- |
|||
| ? | 707-35-52760 | • RING,BACK-UP (KIT) | 1 | SN: 1001- |
|||
| ? | 07000-12075 | • O-RING (KIT) | 1 | SN: 1001- |
|||
| ? | 22F-63-66120 | • ROD,PISTON | 1 | SN: 1001- |
|||
| ? | 707-76-40610 | • BUSHING | 1 | SN: 1001- |
|||
| ? | 07145-00040 | • SEAL,DUST (KIT) | 2 | SN: 1001- |
|||
| ? | 707-36-75470 | • PISTON | 1 | SN: 1001- |
|||
| ? | 707-44-75180 | • RING,PISTON (KIT) | 1 | SN: 1001- |
|||
| ? | 707-39-75190 | • RING,WEAR (KIT) | 1 | SN: 1001- |
|||
| ? | 707-67-33010 | • NUT | 1 | SN: 1001- |
|||
| ? | 07020-00675 | • FITTING,GREASE | 1 | SN: 1001- |
|||
| ? | 22F-63-66181 | TUBE | 1 | SN: 1001- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 1001- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 1001- |
|||
| ? | 07235-10315 | ELBOW | 1 | SN: 1001- |
|||
| ? | 07002-12034 | O-RING (KIT) | 1 | SN: 1001- |
|||
| ? | ==================== | ||||||
| ? | SERVICE KIT | ||||||
| ? | 707-98-23810 | SERVICE KIT,ARM CYLINDER | 1 | SN: 1001- |
