| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-3S-00270) | PUMP ASS'Y | 1 | SN: 3240- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-21A0 T0 Y1600-26A0. | ||||||
| ? | (★705-41-07060) | • GEAR PUMP ASS'Y | 1 | SN: 3240- |
|||
| ? | (★705-41-81310) | • • BRACKET ASS'Y | 1 | SN: 3240- |
|||
| ? | (★705-41-81020) | • • • BRACKET | 1 | SN: 1001- |
|||
| ? | (★705-40-84610) | • • • BUSHING,PLANE | 1 | SN: 3240- |
|||
| ? | (★705-40-84620) | • • • BUSHING,PLANE | 1 | SN: 3240- |
|||
| ? | (★705-40-20C10) | • • CARRIER ASS'Y | 1 | SN: 3240- |
|||
| ? | (★705-40-20C20) | • • • CARRIER | 1 | SN: 3240- |
|||
| ? | (★705-40-84610) | • • • BUSHING,PLANE | 2 | SN: 3240- |
|||
| ? | (★705-40-84620) | • • • BUSHING,PLANE | 2 | SN: 3240- |
|||
| ? | (★705-40-83720) | • • PLATE,SIDE | 4 | SN: 3240- |
|||
| ? | (★705-40-80760) | • • SEAL | 2 | SN: 1001- |
|||
| ? | (★705-40-20790) | • • GEAR,DRIVE | 1 | SN: 3240- |
|||
| ? | (★705-40-20910) | • • GEAR,DRIVEN | 1 | SN: 3240- |
|||
| ? | (★04020-00820) | • • PIN,DOWEL | 4 | SN: 3240- |
|||
| ? | (★01252-71290) | • • BOLT | 4 | SN: 3240- |
|||
| ? | (★01643-51232) | • • WASHER | 4 | SN: 1001- |
|||
| ? | (★705-40-83760) | • • SEAL | 2 | SN: 3240- |
|||
| ? | (★705-40-80880) | • • PLATE | 2 | SN: 3240- |
|||
| ? | (★705-40-17940) | • • HOUSING ASS'Y | 1 | SN: 3240- |
|||
| ? | (★705-40-17950) | • • • HOUSING | 1 | SN: 3240- |
|||
| ? | (★705-40-84610) | • • • BUSHING,PLANE | 1 | SN: 3240- |
|||
| ? | (★705-40-84620) | • • • BUSHING,PLANE | 1 | SN: 3240- |
|||
| ? | (★705-40-80980) | • • • PLUG | 1 | SN: 3240- |
|||
| ? | (★705-40-17860) | • • GEAR,DRIVE | 1 | SN: 3240- |
|||
| ? | (★705-40-17910) | • • GEAR,DRIVEN | 1 | SN: 3240- |
