| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-3S-00270) | PUMP ASS'Y | 1 | SN: 3240- |
|||
| ? | (708-3S-00230) | PUMP ASS'Y | 1 | SN: 1001-3239 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-21A0 TO Y1600-26A0. | ||||||
| ? | (708-3S-01230) | • PUMP SUB ASS'Y | 1 | SN: 1001- |
|||
| ? | (★708-3S-03730) | • • VALVE ASS'Y,LS | 1 | SN: 1001- |
|||
| ? | (★708-1T-15521) | • • • PISTON | 1 | SN: 1001- |
|||
| ? | (★708-3S-15510) | • • • SLEEVE | 1 | SN: 1001- |
|||
| ? | (★708-3S-15520) | • • • SPOOL | 1 | SN: 1001- |
|||
| ? | (★708-1T-15810) | • • • SEAT | 1 | SN: 1001- |
|||
| ? | (★708-1T-16850) | • • • SPRING | 1 | SN: 1001- |
|||
| ? | (★708-1T-15770) | • • • SEAT | 1 | SN: 1001- |
|||
| ? | (★708-1T-15790) | • • • PLUG | 1 | SN: 1001- |
|||
| ? | (★07000-11008) | • • • O-RING | 1 | SN: 1001- |
|||
| ? | (★07001-01008) | • • • RING | 1 | SN: 1001- |
|||
| ? | (★01583-11408) | • • • NUT | 1 | SN: 1001- |
|||
| ? | 07002-12034 | • • • O-RING | 1 | SN: 1001- |
|||
| ? | (★708-1T-15560) | • • • PLUG | 1 | SN: 1001- |
|||
| ? | (★708-1T-15570) | • • • SPRING | 1 | SN: 1001- |
|||
| ? | (★708-1T-15580) | • • • BALL | 1 | SN: 1001- |
|||
| ? | 708-3S-14220 | • • FLANGE | 1 | SN: 1001- |
|||
| ? | 07000-12018 | • • O-RING | 1 | SN: 1001- |
|||
| ? | 01252-60516 | • • BOLT | 2 | SN: 1001- |
