| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-3S-00332 | PUMP ASS'Y | 1 | SN: 3775- |
|||
| ? | 708-3S-00331 | PUMP ASS'Y | 1 | SN: 3240-3774 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0A TO Y1600-06A0A . | ||||||
| ? | 708-3S-01321 | • PUMP SUB ASS'Y | 1 | SN: 3775- |
|||
| ? | 708-3S-01320 | • PUMP SUB ASS'Y | 1 | SN: 3240-3774 |
|||
| ? | (★708-1S-04252) | • • CASE SUB ASS'Y | 1 | SN: 3240- |
|||
| ? | ☆ | • • • CASE,PUMP | 1 | SN: 3240- |
|||
| ? | ☆ | • • • PLUG | 5 | SN: 3240- |
|||
| ? | ☆ | • • • PLUG | 2 | SN: 3240- |
|||
| ? | (★708-1S-13411) | • • CAM,ROCKER | 1 | SN: 3240- |
|||
| ? | (★04260-01270) | • • BALL | 1 | SN: 3240- |
|||
| ? | (★708-1S-14611) | • • SPACER | 1 | SN: 3240- |
|||
| ? | (★708-1S-13420) | • • PIN | 2 | SN: 3240- |
|||
| ? | (★01252-60616) | • • BOLT | 1 | SN: 3240- |
|||
| ? | (★01252-61235) | • • BOLT | 4 | SN: 3240- |
|||
| ? | (★04020-01024) | • • PIN | 2 | SN: 3240- |
|||
| ? | (★07000-11006) | • • O-RING | 4 | SN: 3240- |
|||
| ? | (★07000-12125) | • • O-RING | 1 | SN: 3240- |
|||
| ? | (★708-3S-04250) | • • CAP SUB ASS'Y | 1 | SN: 3774- |
|||
| ? | (★708-3S-04240) | • • CAP SUB ASS'Y | 1 | SN: 3240-3774 |
|||
| ? | ☆ | • • • CAP,END | 1 | SN: 3775- |
|||
| ? | ☆ | • • • CAP,END | 1 | SN: 3240-3774 |
|||
| ? | ☆ | • • • PLUG | 6 | SN: 3240- |
|||
| ? | (★708-21-12760) | • • BEARING | 1 | SN: 1001- |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: 1001- |
|||
| ? | (★708-1S-13430) | • • BALL | 2 | SN: 3240- |
|||
| ? | (★708-7T-16460) | • • BALL | 2 | SN: 1001- |
|||
| ? | (★708-3S-11530) | • • PLUG | 2 | SN: 3240- |
|||
| ? | (★07000-11010) | • • O-RING | 2 | SN: 3240- |
|||
| ? | (★708-3S-12121) | • • SHAFT | 1 | SN: 3240- |
|||
| ? | (★708-3S-12210) | • • BEARING | 1 | SN: 1001- |
|||
| ? | (★708-21-12840) | • • RING,SNAP | 1 | SN: 1001- |
|||
| ? | (★708-1S-19910) | • • HOLDER | 1 | SN: 3240- |
|||
| ? | 207-09-11140 | • • O-RING | 1 | SN: 3240- |
|||
| ? | 708-7T-12230 | • • SEAL,OIL | 1 | SN: 3240- |
|||
| ? | 04065-06220 | • • RING | 1 | SN: 3240- |
