| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-3S-00210 | PUMP ASS'Y | 1 | SN: 1001-3239 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-06A0. | ||||||
| ? | 708-3S-01210 | • PUMP SUB ASS'Y | 1 | SN: 1001-3239 |
|||
| ? | (★708-3S-04110) | • • CASE SUB ASS'Y | 1 | SN: 1001-3239 |
|||
| ? | ☆ | • • • CASE,PUMP | 1 | SN: 1001-3239 |
|||
| ? | ☆ | • • • PLUG | 3 | SN: 1001-3239 |
|||
| ? | ☆ | • • • CAM,ROCKER | 1 | SN: 1001-3239 |
|||
| ? | 01252-61250 | • • BOLT | 4 | SN: 1001-3239 |
|||
| ? | 04020-00616 | • • PIN | 1 | SN: 1001-3239 |
|||
| ? | 07000-11009 | • • O-RING | 4 | SN: 1001-3239 |
|||
| ? | 708-7T-51210 | • • O-RING | 1 | SN: 1001-3239 |
|||
| ? | (★708-3S-04210) | • • CAP SUB ASS'Y | 1 | SN: 1001-3239 |
|||
| ? | ☆ | • • • CAP,END | 1 | SN: 1001-3239 |
|||
| ? | ☆ | • • • PLUG | 13 | SN: 1001-3239 |
|||
| ? | (★708-21-12760) | • • BEARING | 1 | SN: 1001-@ |
|||
| ? | 720-68-19610 | • • PIN | 1 | SN: 1001-@ |
|||
| ? | (★708-3S-15311) | • • SPOOL | 1 | SN: 1001-3239 |
|||
| ? | (★708-3S-15320) | • • SPRING | 1 | SN: 1001-3239 |
|||
| ? | (★708-3S-15330) | • • PLUG | 1 | SN: 1001-3239 |
|||
| ? | 07002-11223 | • • O-RING | 1 | SN: 1001-3239 |
|||
| ? | 708-7T-16460 | • • BALL | 2 | SN: 1001-@ |
|||
| ? | ☆ | • • PLUG | 2 | SN: 1001-3239 |
|||
| ? | (★708-3S-12110) | • • SHAFT | 1 | SN: 1001-3239 |
|||
| ? | (★708-3S-12210) | • • BEARING | 1 | SN: 1001-@ |
|||
| ? | 708-21-12840 | • • RING,SNAP | 1 | SN: 1001-@ |
|||
| ? | (★708-3S-12220) | • • COVER | 1 | SN: 1001-3239 |
|||
| ? | 708-1T-11880 | • • SEAL,OIL | 1 | SN: 1001-3239 |
|||
| ? | 07000-12060 | • • O-RING | 1 | SN: 1001-3239 |
|||
| ? | 04065-06525 | • • RING | 1 | SN: 1001-3239 |
