| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20U-43-21320 | LEVER | 1 | SN: 35001- |
|||
| ? | 01010-81030 | BOLT | 1 | SN: 35001- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: 35001- |
|||
| ? | 20T-06-71110 | SWITCH ? KNOB | 1 | SN: 35001- |
|||
| ? | 20T-43-71190 | NUT | 1 | SN: 35001- |
|||
| ? | 08036-10810 | CLIP | 1 | SN: 35001- |
|||
| ? | 08034-30521 | BAND | 1 | SN: 35001- |
|||
| ? | 20T-43-71161 | BOOT | 1 | SN: 37766- |
|||
| ? | 20T-43-71160 | BOOT | 1 | SN: 35001-37765 |
|||
| ? | 20T-43-71361 | • PLATE | 1 | SN: 37766- |
|||
| ? | 20T-43-71360 | • PLATE | 1 | SN: 35001-37765 |
|||
| ? | (702-16-01181) | PILOT VALVE,(SEE FIG.Y1670-11A0) | 1 | SN: 37428- |
|||
| ? | (702-16-01180) | PILOT VALVE,(SEE FIG.Y1670-11A0) | 1 | SN: 35001-37427 |
|||
| ? | 01010-80820 | BOLT | 3 | SN: 35001- |
|||
| ? | 01643-30823 | WASHER | 3 | SN: 35001- |
|||
| ? | 702-16-53240 | PLUG,(WITHOUT 1 ATT AND PAT) | 1 | SN: 35001- |
|||
| ? | 07000-02018 | O-RING | 2 | SN: 35001- |
|||
| ? | 203-62-57730 | BOLT,(WITHOUT 1 ATT AND PAT) | 1 | SN: 35001- |
|||
| ? | 07000-02018 | O-RING | 2 | SN: 35001- |
|||
| ? | 07230-20210 | UNION | 2 | SN: 35001- |
|||
| ? | 07236-10210 | ELBOW | 2 | SN: 35001- |
|||
| ? | 07002-01423 | O-RING | 4 | SN: 35001- |
|||
| ? | 20T-62-77771 | HOSE ? 1800MM | 1 | SN: 35001- |
|||
| ? | 20T-62-83280 | HOSE ? 1650MM | 1 | SN: 35001- |
|||
| ? | 20T-62-83240 | HOSE ? 1500MM | 1 | SN: 35001- |
|||
| ? | 20U-62-22190 | • O-RING | 1 | SN: 35001- |
|||
| ? | 20T-62-83240 | HOSE ? 1500MM | 1 | SN: 35001- |
|||
| ? | 20U-62-22190 | • O-RING | 1 | SN: 35001- |
|||
| ? | 20T-62-83240 | HOSE ? 1500MM | 1 | SN: 35001- |
|||
| ? | 20U-62-22190 | • O-RING | 1 | SN: 35001- |
|||
| ? | 20T-62-83240 | HOSE ? 1500MM | 1 | SN: 35001- |
|||
| ? | 20U-62-22190 | • O-RING | 1 | SN: 35001- |
|||
| ? | 203-62-32450 | COVER | 1 | SN: 35001- |
|||
| ? | 20T-54-71700 | BOX ASS'Y,(WITHOUT ONE TOUCH DECEL) | 1 | SN: 35001- |
|||
| ? | 20T-910-8590 | BOX ASS'Y,(FOR 1 ATTACHMENT AND PAT) | 1 | SN: 35001- |
|||
| ? | 20T-54-71322 | • BOX,(WITHOUT ONE TOUCH DECEL) | 1 | SN: 35001- |
|||
| ? | 20T-910-8690 | • BOX,(FOR 1 ATTACHMENT AND PAT) | 1 | SN: 35001- |
|||
| ? | 20T-54-71323 | BOX,(FOR ONE TOUCH DECEL) | 1 | SN: 35001- |
|||
| ? | 20T-910-8690 | BOX,(FOR 1 ATT AND PAT AND DECEL) | 1 | SN: 35001- |
|||
| ? | 20T-54-71520 | • PLATE,(WITHOUT ONE TOUCH DECEL) | 1 | SN: 35001- |
|||
| ? | 20T-54-71530 | • PLUG,(WITHOUT ONE TOUCH DECEL) | 1 | SN: 35001- |
|||
| ? | 20T-54-71570 | BOLT | 2 | SN: 35001- |
|||
| ? | 20T-54-71550 | BOLT | 2 | SN: 35001- |
|||
| ? | 01643-70823 | WASHER | 4 | SN: 35001- |
|||
| ? | 20T-43-71480 | SCREW | 1 | SN: 35001- |
|||
| ? | 01643-70823 | WASHER | 1 | SN: 35001- |
|||
| ? | (7824-84-3001) | MONITOR ASS'Y,(CANOPY) (SEE FIG.K1110-51A0) | 1 | SN: 35001- |
|||
| ? | (7824-84-2001) | MONITOR ASS'Y,(CAB) (SEE FIG.K1110-51A1) | 1 | SN: 35001- |
|||
| ? | 20T-06-71431 | BRACKET | 4 | SN: 35001- |
|||
| ? | 01580-10605 | NUT | 4 | SN: 35001- |
|||
| ? | 01641-20608 | WASHER | 4 | SN: 35001- |
|||
| ? | 01602-20619 | WASHER,SPRING | 4 | SN: 35001- |
|||
| ? | 04205-10835 | PIN,(FOR CAB) | 1 | SN: 35001- |
|||
| ? | 04052-10833 | PIN,(FOR CAB) | 1 | SN: 35001- |
