| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20T-54-00800 | OPERATOR'S CAB ASS'Y | 1 | SN: 35001- |
|||
| ? | 20T-54-00850 | OPERATOR'S CAB ASS'Y | 1 | SN: 35001- |
|||
| ? | 20T-54-00860 | OPERATOR'S CAB ASS'Y | 1 | SN: 35001- |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-07A0. | ||||||
| ? | ☆ | • CABIN | 1 | SN: 35001- |
|||
| ? | ☆ | • CABIN,(WITH HEAD GUARD) | 1 | SN: 35001- |
|||
| ? | ☆ | • CABIN,(TOPS) | 1 | SN: 35001- |
|||
| ? | 20T-54-84750 | • WINDOW,L.H. ? UPPER | 1 | SN: 35001- |
|||
| ? | 20U-54-24971 | • DAM | 1 | SN: 35001- |
|||
| ? | 20U-54-25151 | • TRIM | 1 | SN: 35001- |
|||
| ? | 20T-54-84980 | • SEAL,(FOR HEAD GUARD AND TOPS) | 1 | SN: 35001- |
|||
| ? | 20T-54-84760 | • WINDOW,L.H. ? LOWER | 1 | SN: 35001- |
|||
| ? | 20U-54-24981 | • DAM | 1 | SN: 35001- |
|||
| ? | 20T-54-84771 | • WINDOW,REAR | 1 | SN: 35001- |
|||
| ? | 20U-54-24991 | • DAM | 1 | SN: 35001- |
|||
| ? | 20T-54-84871 | • LINING | 1 | SN: 35001- |
|||
| ? | 20T-54-84881 | • COVER | 1 | SN: 35001- |
|||
| ? | 20U-54-25170 | • SEAL | 1 | SN: 35001- |
|||
| ? | 20T-54-75121 | • DUCT | 1 | SN: 35001- |
|||
| ? | 20T-54-75120 | • DUCT,(FOR HEAD GUARD AND TOPS) | 1 | SN: 35001- |
|||
| ? | 21W-54-14690 | • CLIP | 2 | SN: 35001- |
|||
| ? | 21W-54-14690 | • CLIP,(FOR HEAD GUARD AND TOPS) | 3 | SN: 35001- |
|||
| ? | 20T-54-84830 | • DUCT,(FOR TOPS) | 1 | SN: 35001- |
|||
| ? | 20U-54-24681 | • TAPE | 2 | SN: 35001- |
|||
| ? | 20U-54-25140 | • STOPPER | 4 | SN: 35001- |
|||
| ? | 20T-54-84960 | • SHEET | 1 | SN: 35001- |
|||
| ? | 20T-54-84710 | • GLASS | 1 | SN: 35001- |
|||
| ? | 20U-54-24721 | • STRIP,WEATHER | 1 | SN: 35001- |
|||
| ? | 20T-54-84720 | • STRIP,WEATHER | 1 | SN: 35001- |
|||
| ? | 20T-54-84940 | • SASH ASS'Y | 1 | SN: 35001- |
|||
| ? | ACMRBFRA190900 | • • FRAME | 1 | SN: 35001- |
|||
| ? | ACMRBGLA190910 | • • GLASS,UPPER | 1 | SN: 35001- |
|||
| ? | ACMRBGLA190920 | • • GLASS,LOWER | 1 | SN: 35001- |
|||
| ? | ACMRBLOC190930 | • • LOCK ASS'Y | 1 | SN: 35001- |
|||
| ? | ACMRBRAN190940 | • • TRIM,UPPER | 1 | SN: 35001- |
|||
| ? | ACMRBRAN190950 | • • TRIM,LOWER | 1 | SN: 35001- |
|||
| ? | ACMRBCHA190960 | • • CHANNEL | 1 | SN: 35001- |
|||
| ? | ACMRBSTP190970 | • • STOPPER | 2 | SN: 35001- |
|||
| ? | ACMRBSTP190980 | • • STOPPER | 2 | SN: 35001- |
|||
| ? | 20T-54-84731 | • WINDOW,UPPER | 1 | SN: 35001- |
|||
| ? | 20T-54-84741 | • STRIP,WEATHER | 1 | SN: 35001- |
|||
| ? | 20T-54-75210 | • GROMMET | 4 | SN: 35001- |
|||
| ? | 08037-01008 | • GROMMET | 1 | SN: 35001- |
|||
| ? | 09415-01008 | • CAP | 4 | SN: 35001- |
|||
| ? | 09415-00706 | • CAP | 2 | SN: 35001- |
|||
| ? | 01220-40412 | • SCREW | 4 | SN: 35001- |
|||
| ? | 01641-20405 | • WASHER | 4 | SN: 35001- |
|||
| ? | 01220-40612 | • SCREW | 2 | SN: 35001- |
|||
| ? | 01641-20608 | • WASHER | 2 | SN: 35001- |
|||
| ? | 01370-00412 | • SCREW | 3 | SN: 35001- |
