| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-1T-00142) | PUMP ASS'Y | 1 | SN: 36768- |
|||
| ? | (708-1T-00141) | PUMP ASS'Y | 1 | SN: 35001-36767 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-06A0. | ||||||
| ? | (708-1T-01122) | • PUMP SUB ASS'Y | 1 | SN: 36768- |
|||
| ? | (708-1T-01121) | • PUMP SUB ASS'Y | 1 | SN: 35001-36767 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-04A0. | ||||||
| ? | (★708-1T-13110) | • • BLOCK,CYLINDER | 1 | SN: 35001- |
|||
| ? | (★708-1T-13221) | • • PLATE,VALVE | 1 | SN: 35001- |
|||
| ? | (★708-1T-13130) | • • WASHER | 2 | SN: 35001- |
|||
| ? | (★708-1T-13151) | • • SPRING | 1 | SN: 35001- |
|||
| ? | 04065-03815 | • • RING | 1 | SN: 35001- |
|||
| ? | (★708-1T-13350) | • • RETAINER,GUIDE | 1 | SN: 35001- |
|||
| ? | 708-2L-23360 | • • PIN | 3 | SN: 35001- |
|||
| ? | (★708-1T-13340) | • • RETAINER,SHOE | 1 | SN: 35001- |
|||
| ? | (★708-1T-13310) | • • PISTON SUB ASS'Y | 7 | SN: 35001- |
|||
| ? | (★708-1T-14210) | • • BOLT,ADJUST | 1 | SN: 35001- |
|||
| ? | 07002-13034 | • • O-RING | 1 | SN: 35001- |
|||
| ? | (★708-1T-14311) | • • PLUG | 1 | SN: 35001- |
|||
| ? | 01583-02414 | • • • NUT | 1 | SN: 35001- |
|||
| ? | 07002-12434 | • • O-RING | 1 | SN: 35001- |
|||
| ? | (★708-1T-15141) | • • PLUG | 1 | SN: 35001- |
|||
| ? | 01582-01210 | • • NUT | 1 | SN: 35001- |
|||
| ? | 07002-11223 | • • O-RING | 1 | SN: 35001- |
|||
| ? | (★708-1T-15121) | • • SEAT | 1 | SN: 35001- |
|||
| ? | (★708-1T-14410) | • • SLIDER | 1 | SN: 35001- |
|||
| ? | 708-1T-15590 | • • SEAT | 1 | SN: 35001- |
