| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (20S-26-00202) | SWING MACHINERY A. | 1 | SN: 37320- |
|||
| ? | (20S-26-00201) | SWING MACHINERY A. | 1 | SN: 36768-37319 |
|||
| ? | (20S-26-00200) | SWING MACHINERY A. | 1 | SN: 35001-36767 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.N1200-01A0 AND N1200-02A0. | ||||||
| ? | (708-7R-00024) | • MOTOR ASS'Y | 1 | SN: 37320- |
|||
| ? | (708-7R-00023) | • MOTOR ASS'Y,(SEE FIG.Y1640-01A0) | 1 | SN: 36768-37319 |
|||
| ? | (708-7R-00022) | • MOTOR ASS'Y,(SEE FIG.Y1640-01A0) | 1 | SN: 35001-36767 |
|||
| ? | 20S-26-81310 | • RING | 1 | SN: 35001- |
|||
| ? | 07000-02135 | • O-RING | 1 | SN: 35001- |
|||
| ? | 07230-20315 | • UNION | 3 | SN: 35001- |
|||
| ? | 07002-12034 | • O-RING | 3 | SN: 35001- |
|||
| ? | 07230-20210 | • UNION | 1 | SN: 35001- |
|||
| ? | 07002-11423 | • O-RING | 1 | SN: 35001- |
|||
| ? | 20T-62-71610 | • TEE | 1 | SN: 35001- |
|||
| ? | 07002-11423 | • O-RING | 1 | SN: 35001- |
|||
| ? | 01010-81235 | BOLT | 6 | SN: 35001- |
|||
| ? | 01643-31232 | WASHER | 6 | SN: 35001- |
|||
| ? | 04020-01434 | PIN,DOWEL | 2 | SN: 35001- |
