| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20S-26-00202 | SWING MACHINERY A. | 1 | SN: 37320- |
|||
| ? | 20S-26-00201 | SWING MACHINERY A. | 1 | SN: 36768-37319 |
|||
| ? | 20S-26-00200 | SWING MACHINERY A. | 1 | SN: 35001-36767 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.N1200-01A0 AND N1200-02A0. | ||||||
| ? | 20S-26-81180 | • CARRIER | 1 | SN: 35001- |
|||
| ? | 20S-26-81121 | • GEAR | 3 | SN: 35001- |
|||
| ? | 20S-26-81260 | • PIN | 3 | SN: 35001- |
|||
| ? | 20T-26-81430 | • BEARING | 3 | SN: 35001- |
|||
| ? | 20S-26-71160 | • WASHER | 12 | SN: 35001- |
|||
| ? | 20S-26-71190 | • RING,SNAP | 6 | SN: 35001- |
|||
| ? | 20S-26-71250 | • PIN | 6 | SN: 35001- |
|||
| ? | 20S-26-81190 | • CARRIER | 1 | SN: 35001- |
|||
| ? | 20S-26-81140 | • GEAR | 3 | SN: 35001- |
|||
| ? | 20S-26-81250 | • PIN | 3 | SN: 35001- |
|||
| ? | 201-26-62270 | • BEARING | 3 | SN: 35001- |
|||
| ? | 20S-26-81151 | • GEAR | 1 | SN: 37218- |
|||
| ? | □20S-26-81150 | • GEAR | 1 | SN: 35001-37217 |
|||
| ? | 20S-26-81231 | • SPACER | 1 | SN: 35001- |
|||
| ? | 20S-26-81160 | • SHAFT | 1 | SN: 35001- |
|||
| ? | 20S-26-81280 | • BEARING | 1 | SN: 35001- |
|||
| ? | 20S-26-81290 | • BEARING | 1 | SN: 35001- |
|||
| ? | 20S-26-81210 | • SEAL | 1 | SN: 35001- |
|||
| ? | 20S-26-81171 | • CASE | 1 | SN: 37218- |
|||
| ? | □20S-26-81170 | • CASE | 1 | SN: 35001-37217 |
|||
| ? | 21T-09-11580 | • BOLT | 5 | SN: 35001- |
|||
| ? | 01252-31080 | • BOLT | 2 | SN: 35001- |
|||
| ? | 01643-51032 | • WASHER | 7 | SN: 35001- |
|||
| ? | 20S-26-81240 | • WASHER,THRUST | 2 | SN: 35001- |
|||
| ? | 20S-26-81220 | • SEAL,OIL | 1 | SN: 35001- |
|||
| ? | 20S-26-81110 | • GEAR | 1 | SN: 35001- |
|||
| ? | 20S-26-81130 | • GEAR | 1 | SN: 35001- |
|||
| ? | 07049-01215 | • PLUG | 2 | SN: 35001- |
|||
| ? | 04064-04218 | • RING,SNAP | 1 | SN: 35001- |
