| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 07371-30400 | FLANGE | 6 | SN: 10001- |
|||
| ? | 07000-12021 | O-RING | 3 | SN: 10001- |
|||
| ? | 01010-50830 | BOLT | 12 | SN: 10001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 12 | SN: 10001- |
|||
| ? | 20T-62-66490 | HOSE | 1 | SN: 11574- |
|||
| ? | □20T-62-66220 | HOSE | 1 | SN: 10001-11573 |
|||
| ? | 20T-62-66480 | HOSE | 1 | SN: 11574- |
|||
| ? | □20T-62-66210 | HOSE | 1 | SN: 10001-11573 |
|||
| ? | 20T-62-66470 | HOSE | 1 | SN: 11574- |
|||
| ? | □20T-62-66190 | HOSE | 1 | SN: 10001-11573 |
|||
| ? | 203-62-32440 | COVER | 2 | SN: 10001- |
|||
| ? | 20R-62-21520 | ELBOW | 1 | SN: 10001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: 10001- |
|||
| ? | 20R-62-21510 | ELBOW | 1 | SN: 10001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: 10001- |
|||
| ? | 20T-62-61230 | TUBE | 1 | SN: 10001- |
|||
| ? | 07235-10422 | ELBOW | 1 | SN: 10001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: 10001- |
|||
| ? | 08037-03614 | GROMMET | 3 | SN: 10001- |
|||
| ? | (709-36-12703) | VALVE ASS'Y,(SEE FIG.6201) | 1 | SN: 10001- |
|||
| ? | (☒709-36-12702) | VALVE ASS'Y,(SEE FIG.6201) | 1 | SN: (10834-11695) |
|||
| ? | (☒709-36-12701) | VALVE ASS'Y,(SEE FIG.6201) | 1 | SN: (10001-10833) |
|||
| ? | (709-33-11902) | VALVE ASS'Y,(SEE FIG.6211) | 1 | SN: 11899- |
|||
| ? | 709-33-11901 | VALVE ASS'Y,(SEE FIG.6211) | 1 | SN: 10001-11898 |
|||
| ? | (☒709-33-11900) | VALVE ASS'Y,(SEE FIG.6211) | 1 | SN: (10001-11695) |
|||
| ? | 20S-60-31211 | BRACKET | 1 | SN: 10748- |
|||
| ? | ▩20S-60-31210 | BRACKET | 1 | SN: 10001-10747 |
|||
| ? | (20S-60-31211{203-62-58360(6) ?} | ||||||
| ? | 07000-03025(9)) | ||||||
| ? | 203-62-58360 | CUSHION | 6 | SN: 10748- |
|||
| ? | 203-62-42770 | CUSHION | 6 | SN: 10001-10747 |
|||
| ? | 20X-62-21550 | SPACER | 3 | SN: 10001- |
|||
| ? | 07000-03025 | O-RING | 9 | SN: 10748- |
|||
| ? | 07000-03025 | O-RING | 3 | SN: 10001-10747 |
|||
| ? | 566-35-42430 | PLATE | 3 | SN: 10001- |
|||
| ? | 01010-51250 | BOLT | 3 | SN: 10001- |
|||
| ? | 01643-31232 | WASHER | 3 | SN: 10001- |
|||
| ? | 01010-50825 | BOLT | 6 | SN: 10001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 6 | SN: 10001- |
