| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 312610614 | UNION | 2 | SN: 140F10001-140F10407 |
|||
| ? | 855051111 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051011 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 392435010 | HOSE | 1 | SN: 140F10001-140F10407 |
|||
| ? | 500380870 | UNION | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051011 | • O-RING | 2 | SN: 140F10001-140F10407 |
|||
| ? | 500380113 | UNION | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051119 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051018 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 392805029 | HOSE | 1 | SN: 140F10001-140F10407 |
|||
| ? | 500380874 | UNION | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051018 | • O-RING | 2 | SN: 140F10001-140F10407 |
|||
| ? | 500380113 | UNION | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051119 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051018 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 500380516 | ELBOW | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051217 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051021 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 392403001 | HOSE | 1 | SN: 140F10001-140F10407 |
|||
| ? | 312610062 | PIPE | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051021 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 500380116 | UNION | 2 | SN: 140F10001-140F10407 |
|||
| ? | 855051217 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855051021 | • O-RING | 1 | SN: 140F10001-140F10407 |
|||
| ? | 855050078 | GASKET | 1 | SN: 140F10001-140F10407 |
|||
| ? | 845190008 | VALVE | 1 | SN: 140F10001-140F10407 |
|||
| ? | SEE FIG. 6290 | 6290 | |||||
| ? | SEE FIG. 6510 | 6510 | |||||
| ? | SEE FIG. 6530 | 6530 |
