| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 144-43-16630 | SHAFT | 1 | SN: 50001- |
|||
| ? | 01306-00616 | SCREW | 1 | SN: 50001- |
|||
| ? | 04059-01012 | WIRE,LOCK | 1 | SN: 50001- |
|||
| ? | 144-43-16621 | BRACKET | 1 | SN: 50001- |
|||
| ? | 06120-02016 | BEARING | 2 | SN: 50001- |
|||
| ? | 06122-02004 | SEAL,BEARING | 2 | SN: 50001- |
|||
| ? | 07020-00900 | FITTING,GREASE | 1 | SN: 50001- |
|||
| ? | 01010-51230 | BOLT | 4 | SN: 50001- |
|||
| ? | 01602-21236 | WASHER,SPRING | 4 | SN: 50001- |
|||
| ? | 144-43-16640 | LEVER | 1 | SN: 50001- |
|||
| ? | 04010-00519 | KEY | 1 | SN: 50001- |
|||
| ? | 01010-50830 | BOLT | 1 | SN: 50001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 1 | SN: 50001- |
|||
| ? | 04250-41056 | END | 1 | SN: 50001- |
|||
| ? | 04252-01061 | END | 1 | SN: 50001- |
|||
| ? | 01582-11008 | NUT | 1 | SN: 50001- |
|||
| ? | 01593-11008 | NUT | 2 | SN: 50001- |
|||
| ? | 04050-12018 | PIN | 2 | SN: 50001- |
|||
| ? | 14F-43-81120 | LEVER | 1 | SN: 50001- |
|||
| ? | 06120-01612 | BEARING | 2 | SN: 50001- |
|||
| ? | 06122-01603 | SEAL,BEARING | 2 | SN: 50001- |
|||
| ? | 135-43-11171 | SHAFT | 1 | SN: 50001- |
|||
| ? | 07020-00900 | FITTING,GREASE | 1 | SN: 50001- |
|||
| ? | 04250-41056 | END | 1 | SN: 50001- |
|||
| ? | 04250-61056 | END,L.H. THREAD | 1 | SN: 50001- |
|||
| ? | 04248-31032 | ROD | 1 | SN: 50001- |
|||
| ? | 01582-11008 | NUT | 1 | SN: 50001- |
|||
| ? | 01508-41006 | NUT,L.H. THREAD | 1 | SN: 50001- |
|||
| ? | 01593-11008 | NUT | 2 | SN: 50001- |
|||
| ? | 04050-12018 | PIN,COTTER | 2 | SN: 50001- |
|||
| ? | 144-43-16650 | BRACKET | 1 | SN: 50001- |
|||
| ? | 01010-51025 | BOLT | 2 | SN: 50001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 50001- |
|||
| ? | 131-60-42160 | SPRING | 1 | SN: 50001- |
|||
| ? | 04260-01270 | BALL | 1 | SN: 50001- |
|||
| ? | 120-43-32761 | LEVER | 1 | SN: 50001- |
|||
| ? | 01010-50655 | BOLT | 1 | SN: 50001- |
|||
| ? | 01602-20619 | WASHER,SPRING | 1 | SN: 50001- |
|||
| ? | 144-43-16660 | SHAFT | 1 | SN: 50001- |
|||
| ? | 04205-10822 | PIN | 1 | SN: 50001- |
|||
| ? | 04050-12012 | PIN,COTTER | 1 | SN: 50001- |
|||
| ? | 04025-00432 | PIN,SPRING | 1 | SN: 50001- |
|||
| ? | 120-43-37251 | NOTCH | 1 | SN: 50001- |
|||
| ? | 144-43-81510 | LEVER | 1 | SN: 50001- |
|||
| ? | 130-43-62140 | COVER | 1 | SN: 50001- |
|||
| ? | 09340-10130 | SPRING | 1 | SN: 50001- |
|||
| ? | 09304-01250 | KNOB | 1 | SN: 50001- |
|||
| ? | 144-43-81650 | COVER,(FOR D60P) | 1 | SN: 51531- |
|||
| ? | □120-43-37293 | COVER,(FOR D60P) | 1 | SN: 50001-51530 |
|||
| ? | 144-43-81650 | COVER,(FOR D65P) | 1 | SN: 50691- |
|||
| ? | □120-43-37293 | COVER,(FOR D65P) | 1 | SN: 50001-50690 |
|||
| ? | 01439-00820 | BOLT,(FOR D60P) | 4 | SN: 51531- |
|||
| ? | 01439-00814 | BOLT,(FOR D60P) | 4 | SN: 50001-51530 |
|||
| ? | 01439-00820 | BOLT,(FOR D65P) | 4 | SN: 50691- |
|||
| ? | 01439-00814 | BOLT,(FOR D65P) | 4 | SN: 50001-50690 |
|||
| ? | 07372-21030 | BOLT | 3 | SN: 50001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 3 | SN: 50001- |
