| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 131-60-00084 | TANK ASS'Y | 1 | SN: 10901-15400 |
|||
| ? | 131-60-00083 | TANK ASS'Y | 1 | SN: 7526-10900 |
|||
| ? | 131-60-00082 | TANK ASS'Y | 1 | SN: 5861-7525 |
|||
| ? | 131-60-00081 | TANK ASS'Y | 1 | SN: 3091-5860 |
|||
| ? | 131-60-00080 | TANK ASS'Y | 1 | SN: 1201-3090 |
|||
| ? | D50S-T701E | • TANK | 1 | SN: 10901-15400 |
|||
| ? | D50S-T701D | • TANK | 1 | SN: 5861-10900 |
|||
| ? | D50S-TP701C | • TANK | 1 | SN: 3091-5860 |
|||
| ? | D50S-TP701B | • TANK | 1 | SN: 1201-3090 |
|||
| ? | 131-60-00111 | • VALVE ASS'Y,(SEE FIG.538) | 1 | SN: 10901-15400 |
|||
| ? | 131-60-00110 | • VALVE ASS'Y,(SEE FIG.538) | 1 | SN: 1201-10900 |
|||
| ? | 131-60-00092 | • VALVE ASS'Y,(SEE FIG.527A) | 1 | SN: 10901-@ |
|||
| ? | 131-60-00091 | • VALVE ASS'Y,(SEE FIG.527A) | 1 | SN: 5861-10900 |
|||
| ? | 131-60-00090 | • VALVE ASS'Y,(SEE FIG.527) | 1 | SN: 1201-5860 |
|||
| ? | 01040-31435 | • BOLT | 8 | SN: 10901-15400 |
|||
| ? | 01000-31435 | • BOLT | 8 | SN: 1201-10900 |
|||
| ? | 01602-01442 | • WASHER | 8 | SN: 1201-@ |
|||
| ? | 04020-01434 | • PIN | 2 | SN: 1201-7905 |
|||
| ? | 131-60-13120 | • COVER | 1 | SN: 1201-@ |
|||
| ? | 131-60-13130 | • GASKET | 1 | SN: 1201-@ |
|||
| ? | 01040-31020 | • BOLT | 18 | SN: 10901-@ |
|||
| ? | 01000-31020 | • BOLT | 18 | SN: 1201-10900 |
|||
| ? | 01602-01030 | • WASHER | 18 | SN: 1201-@ |
|||
| ? | 04350-01628 | • BOLT | 2 | SN: 10901-@ |
|||
| ? | 130-60-91340 | • BOLT | 2 | SN: 5861-10900 |
|||
| ? | 180-78-15180 | • HOOK | 2 | SN: 1201-5860 |
|||
| ? | 01602-01648 | • WASHER | 2 | SN: 10901-@ |
|||
| ? | 01602-01442 | • WASHER | 2 | SN: 1201-10900 |
|||
| ? | D50S-T708B | • FILLER | 1 | SN: 7526-15400 |
|||
| ? | D50S-T708A | • FILLER | 1 | SN: 1201-7525 |
|||
| ? | 131-60-13150 | • GASKET | 1 | SN: 1201-15400 |
|||
| ? | 01040-31025 | • BOLT | 4 | SN: 10901-@ |
|||
| ? | 01000-31025 | • BOLT | 4 | SN: 1201-10900 |
|||
| ? | 01602-01030 | • WASHER | 4 | SN: 1201-@ |
|||
| ? | 131-60-13170 | • STRAINER | 1 | SN: 1201-@ |
|||
| ? | 180-78-15160 | • CAP | 1 | SN: 1201-@ |
|||
| ? | 131-60-13161 | • GAUGE | 1 | SN: 1201-@ |
|||
| ? | 131-60-91420 | • TUBE | 1 | SN: 1201-15400 |
|||
| ? | D50S-T750 | • CLIP | 2 | SN: 1201-15400 |
|||
| ? | D50S-T778 | • SEAT | 1 | SN: 1201-10900 |
|||
| ? | D50S-T779 | • GASKET | 1 | SN: 1201-10900 |
|||
| ? | 01000-31020 | • BOLT | 4 | SN: 1201-10900 |
|||
| ? | 01602-01030 | • WASHER | 4 | SN: 1201-10900 |
|||
| ? | 07044-03620 | • PLUG | 1 | SN: 10901-@ |
|||
| ? | A5710S3342 | • PLUG | 1 | SN: 5861-10900 |
|||
| ? | D50S-T780 | • PLUG | 1 | SN: 1201-5860 |
|||
| ? | D50S-T781 | • MAGNET | 1 | SN: 1201-5860 |
|||
| ? | D50S-T782 | • PIN | 1 | SN: 1201-5860 |
|||
| ? | 07000-03035 | • O-RING | 1 | SN: 10901-@ |
|||
| ? | 130-27-11232 | • GASKET | 1 | SN: 9716-10900 |
|||
| ? | 07003-03642 | • GASKET | 1 | SN: 5861-9715 |
|||
| ? | D50S-T783 | • GASKET | 1 | SN: 1201-5860 |
|||
| ? | D50S-T428B | • SEAT | 1 | SN: 10901-15400 |
|||
| ? | D50S-T428A | • SEAT | 1 | SN: 5861-10900 |
|||
| ? | D50S-T428 | • SEAT | 1 | SN: 1201-5860 |
|||
| ? | 131-60-12161 | • GASKET | 1 | SN: 5861-@ |
|||
| ? | 131-60-12160 | • GASKET | 1 | SN: 1201-5860 |
|||
| ? | 01040-31255 | • BOLT | 18 | SN: 10901-@ |
|||
| ? | 01000-31255 | • BOLT | 18 | SN: 5861-10900 |
|||
| ? | 01000-31255 | • BOLT | 14 | SN: 1201-5860 |
|||
| ? | 01000-31245 | • BOLT | 4 | SN: 1201-5860 |
|||
| ? | 01602-01236 | • WASHER | 18 | SN: 1201-@ |
|||
| ? | 07042-00415 | • PLUG | 5 | SN: 1201-15400 |
|||
| ? | 07042-00211 | • PLUG | 1 | SN: 1201-@ |
|||
| ? | D50S-T714 | • FLANGE | 1 | SN: 1201-15400 |
|||
| ? | 07000-03042 | • O-RING | 1 | SN: 1201-15400 |
|||
| ? | 01040-31265 | • BOLT | 2 | SN: 10901-15400 |
|||
| ? | 01000-31265 | • BOLT | 2 | SN: 1201-10900 |
|||
| ? | 01601-01230 | • WASHER | 2 | SN: 1201-15400 |
|||
| ? | 04065-04518 | • RING | 1 | SN: 10901-@ |
|||
| ? | D50S-T670 | • RING | 1 | SN: 7526-10900 |
|||
| ? | D50S-T436A | • FLANGE | 1 | SN: 10901-15400 |
|||
| ? | D50S-T436 | • FLANGE | 1 | SN: 1201-10900 |
|||
| ? | D50S-T439A | • BOLT | 1 | SN: 10901-15400 |
|||
| ? | D50S-T439 | • BOLT | 1 | SN: 1201-10900 |
|||
| ? | 01041-31200 | • BOLT | 3 | SN: 10901-15400 |
|||
| ? | 01001-31205 | • BOLT | 3 | SN: 1201-10900 |
|||
| ? | 01601-01230 | • WASHER | 4 | SN: 1201-15400 |
|||
| ? | 07000-03030 | • O-RING | 2 | SN: 1201-15400 |
|||
| ? | 131-60-14351 | • JOINT | 2 | SN: 1201-@ |
|||
| ? | 04205-01235 | • PIN | 4 | SN: 1201-15400 |
|||
| ? | 01641-01220 | • WASHER | 4 | SN: 1201-15400 |
|||
| ? | 04050-03020 | • PIN | 4 | SN: 1201-@ |
|||
| ? | 131-60-14322 | • LEVER | 1 | SN: 10901-@ |
|||
| ? | 131-60-14321 | • LEVER | 1 | SN: 1201-10900 |
|||
| ? | 01040-31035 | • BOLT | 1 | SN: 10901-@ |
|||
| ? | 01000-31035 | • BOLT | 1 | SN: 1201-10900 |
|||
| ? | 01601-01025 | • WASHER | 1 | SN: 1201-@ |
|||
| ? | 04010-00725 | • KEY | 1 | SN: 1201-@ |
|||
| ? | 131-60-14282 | • LEVER | 1 | SN: 10901-@ |
|||
| ? | 131-60-14281 | • LEVER | 1 | SN: 1201-10900 |
|||
| ? | 01040-31040 | • BOLT | 1 | SN: 10901-@ |
|||
| ? | 01000-31040 | • BOLT | 1 | SN: 1201-10900 |
|||
| ? | 01602-01030 | • WASHER | 1 | SN: 1201-@ |
|||
| ? | 04000-00725 | • KEY | 1 | SN: 1201-@ |
|||
| ? | D50S-T966B | • LEVER | 1 | SN: 10901-15400 |
|||
| ? | D50S-T966A | • LEVER | 1 | SN: 5861-10900 |
|||
| ? | D50S-T966 | • LEVER | 1 | SN: 1201-5860 |
|||
| ? | 01040-31040 | • BOLT | 1 | SN: 10901-@ |
|||
| ? | 01000-31040 | • BOLT | 1 | SN: 1201-10900 |
|||
| ? | 01602-01030 | • WASHER | 1 | SN: 1201-@ |
|||
| ? | 04000-00725 | • KEY | 1 | SN: 1201-@ |
|||
| ? | D50S-T965C | • LEVER | 1 | SN: .-15400 |
|||
| ? | D50S-T965A | • LEVER | 1 | SN: 10901-. |
|||
| ? | D50S-T965 | • LEVER | 1 | SN: 1201-10900 |
|||
| ? | 01040-31035 | • BOLT | 1 | SN: 10901-@ |
|||
| ? | 01000-31035 | • BOLT | 1 | SN: 1201-10900 |
|||
| ? | 01602-01030 | • WASHER | 1 | SN: 1201-@ |
|||
| ? | 04010-00725 | • KEY | 1 | SN: 1201-15400 |
|||
| ? | D50S-T929C | • SHAFT | 1 | SN: 5861-15400 |
|||
| ? | D50S-T929B | • SHAFT | 1 | SN: 3771-5860 |
|||
| ? | D50S-T929A | • SHAFT | 1 | SN: 1201-3770 |
|||
| ? | D50S-T930C | • SHAFT | 1 | SN: 5861-15400 |
|||
| ? | D50S-T930B | • SHAFT | 1 | SN: 3771-5860 |
|||
| ? | D50S-T930A | • SHAFT | 1 | SN: 1201-3770 |
|||
| ? | 131-60-14211 | • BEARING | 1 | SN: 1201-@ |
|||
| ? | 131-60-14910 | • BUSHING | 1 | SN: 1201-15400 |
|||
| ? | 131-60-14221 | • BUSHING | 1 | SN: 5861-@ |
|||
| ? | 131-60-14220 | • BUSHING | 1 | SN: 1201-5860 |
|||
| ? | 130-09-12310 | • SEAL | 1 | SN: 1201-@ |
|||
| ? | 130-09-11110 | • SEAL | 1 | SN: 1201-@ |
|||
| ? | SB243810 | • SEAL | 1 | SN: 5861-15400 |
|||
| ? | 130-09-12310 | • SEAL | 1 | SN: 1201-5860 |
|||
| ? | 141-60-14150 | • WASHER | 1 | SN: 5861-15400 |
