| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 135-60-00212 | DUMP CYLINDER ASS'Y | 2 | SN: 3344-3688 |
|||
| ? | □135-60-00211 | DUMP CYLINDER ASS'Y | 2 | SN: 3221-3343 |
|||
| ? | □135-60-00210 | DUMP CYLINDER ASS'Y | 2 | SN: 2008-3220 |
|||
| ? | 135-60-00033 | DUMP CYLINDER ASS'Y | 2 | SN: 2002-2007 |
|||
| ? | 135-60-00032 | DUMP CYLINDER ASS'Y | 2 | SN: 1013-1999 |
|||
| ? | (☒135-60-00031) | DUMP CYLINDER ASS'Y | 2 | SN: (1013-1219) |
|||
| ? | 135-60-00030 | DUMP CYLINDER ASS'Y | 2 | SN: 1007-1012 |
|||
| ? | 135-60-25220 | • CYLINDER | 1 | SN: 2008-3688 |
|||
| ? | 135-60-15112 | • CYLINDER | 1 | SN: 1013-2007 |
|||
| ? | 135-60-15111 | • CYLINDER | 1 | SN: 1007-1012 |
|||
| ? | 135-60-15380 | • BUSHING | 1 | SN: 1007-3688 |
|||
| ? | 135-60-25170 | • HEAD | 1 | SN: 2008-3688 |
|||
| ? | 135-60-15141 | • HEAD | 1 | SN: 1007-2007 |
|||
| ? | 01010-62465 | • BOLT | 2 | SN: 3221-3688 |
|||
| ? | 01010-62475 | • BOLT | 2 | SN: 3221-3688 |
|||
| ? | 01040-62465 | • BOLT | 2 | SN: 2008-3220 |
|||
| ? | 01040-62475 | • BOLT | 2 | SN: 2008-3220 |
|||
| ? | 01040-62265 | • BOLT | 4 | SN: 1007-2007 |
|||
| ? | 01602-02472 | • WASHER | 4 | SN: 2008-3688 |
|||
| ? | 01602-02268 | • WASHER | 4 | SN: 1007-2007 |
|||
| ? | 07000-15120 | • O-RING | 1 | SN: 3221-3688 |
|||
| ? | □07000-05120 | • O-RING (KIT) | 1 | SN: 2008-3220 |
|||
| ? | 07000-15110 | • O-RING (KIT) | 1 | SN: 1007-2007 |
|||
| ? | 140-817-8260 | • RING | 1 | SN: 2008-3688 |
|||
| ? | 131-60-45190 | • RING | 1 | SN: 1007-2007 |
|||
| ? | 135-60-25180 | • ROD | 1 | SN: 2008-3688 |
|||
| ? | 135-60-15171 | • ROD | 1 | SN: 1007-2007 |
|||
| ? | 07000-03032 | • O-RING (KIT) | 1 | SN: 1007-1219 |
|||
| ? | 135-60-15190 | • BUSHING | 1 | SN: 1007-3688 |
|||
| ? | 140-09-18120 | • NUT | 1 | SN: 3221-3688 |
|||
| ? | 130-09-18170 | • NUT | 1 | SN: 2008-3220 |
|||
| ? | 135-60-15371 | • NUT | 1 | SN: 1007-2007 |
|||
| ? | (☒135-60-15370) | • NUT | 1 | SN: (1007-1219) |
|||
| ? | 141-60-16440 | • STOPPER | 2 | SN: 2008-3688 |
|||
| ? | 04050-06075 | • PIN | 1 | SN: 1007-1219 |
|||
| ? | 135-60-15210 | • WASHER | 1 | SN: 1007-2007 |
|||
| ? | 135-60-25210 | • PISTON | 1 | SN: 2008-3688 |
|||
| ? | 135-60-15230 | • PISTON | 1 | SN: 1007-2007 |
|||
| ? | 141-60-16271 | • HOLDER | 1 | SN: 2008-3688 |
|||
| ? | 131-60-16232 | • RETAINER | 1 | SN: 1007-2007 |
|||
| ? | 141-60-16271 | • HOLDER | 1 | SN: 2008-3688 |
|||
| ? | 135-60-15270 | • HOLDER | 1 | SN: 1007-2007 |
|||
| ? | 141-60-16261 | • U-RING | 2 | SN: 2008-3688 |
|||
| ? | 131-60-16221 | • U-RING | 2 | SN: 1007-2007 |
|||
| ? | 141-60-16251 | • HEEL | 2 | SN: 2008-3688 |
|||
| ? | 131-60-16212 | • HEEL | 2 | SN: 1007-2007 |
|||
| ? | 141-60-16241 | • RING | 2 | SN: 2008-3688 |
|||
| ? | 131-60-16191 | • RING | 2 | SN: 1007-2007 |
|||
| ? | 141-60-16282 | • BUSHING | 1 | SN: 2008-3688 |
|||
| ? | 140-60-15221 | • BUSHING | 1 | SN: 1007-2007 |
|||
| ? | 131-60-44260 | • HEADER | 1 | SN: 3344-3688 |
|||
| ? | □141-60-16311 | • HEADER | 1 | SN: 2008-3343 |
|||
| ? | 140-60-15590 | • HEADER | 1 | SN: 1002-2007 |
|||
| ? | 04065-08025 | • RING | 1 | SN: 3221-3688 |
|||
| ? | ▩141-60-16291 | • RING | 1 | SN: 2008-3220 |
|||
| ? | (04065-08025{141-60-16321 ?} | ||||||
| ? | 141-60-16331) | ||||||
| ? | 140-60-15610 | • RING | 1 | SN: 1007-2007 |
|||
| ? | 141-60-16321 | • PACKING | 1 | SN: 3221-3688 |
|||
| ? | ▩141-60-16320 | • PACKING | 1 | SN: 2008-3220 |
|||
| ? | (04065-08025{141-60-16321 ?} | ||||||
| ? | 141-60-16331) | ||||||
| ? | 131-60-16271 | • U-RING | 1 | SN: 1007-2007 |
|||
| ? | 141-60-16331 | • HEEL | 1 | SN: 3221-3688 |
|||
| ? | ▩141-60-16330 | • HEEL | 1 | SN: 2008-3220 |
|||
| ? | (04065-08025{141-60-16321 ?} | ||||||
| ? | 141-60-16331) | ||||||
| ? | 140-60-15570 | • HEEL | 1 | SN: 1007-2007 |
|||
| ? | 130-09-11731 | • RING | 1 | SN: 3221-3688 |
|||
| ? | □130-09-11730 | • RING | 1 | SN: 2008-3220 |
|||
| ? | 130-09-11710 | • RING,OIL | 1 | SN: 1007-2007 |
|||
| ? | 07179-00093 | • RING | 1 | SN: 2008-3688 |
|||
| ? | 07179-00082 | • RING | 1 | SN: 2002-2007 |
|||
| ? | 135-60-25150 | FLANGE | 1 | SN: 2002-3688 |
|||
| ? | 135-60-16570 | FLANGE | 1 | SN: 1007-1999 |
|||
| ? | 135-60-25130 | FLANGE | 1 | SN: 2002-3688 |
|||
| ? | 135-60-16580 | FLANGE | 1 | SN: 1007-1999 |
|||
| ? | 07000-23030 | O-RING (KIT) | 4 | SN: 2002-3688 |
|||
| ? | 135-09-17170 | O-RING (KIT) | 4 | SN: 1007-1999 |
|||
| ? | 01010-31470 | BOLT | 4 | SN: 3221-3688 |
|||
| ? | 01040-31470 | BOLT | 4 | SN: 1013-3220 |
|||
| ? | 01040-31450 | BOLT | 4 | SN: 1007-1012 |
|||
| ? | 01010-31470 | BOLT | 4 | SN: 3221-3688 |
|||
| ? | 01040-31450 | BOLT | 4 | SN: 1007-3220 |
|||
| ? | 01602-01442 | WASHER | 8 | SN: 1007-3688 |
|||
| ? | 135-60-25141 | TUBE | 1 | SN: 2008-3688 |
|||
| ? | 135-60-25140 | TUBE | 1 | SN: 2002-2007 |
|||
| ? | 135-60-16342 | TUBE | 1 | SN: 1013-1999 |
|||
| ? | 135-60-16341 | TUBE | 1 | SN: 1007-1012 |
|||
| ? | 135-60-25111 | TUBE | 1 | SN: 2008-3688 |
|||
| ? | 135-60-25110 | TUBE | 1 | SN: 2002-2007 |
|||
| ? | 135-60-16352 | TUBE | 1 | SN: 1013-1999 |
|||
| ? | 135-60-16351 | TUBE | 1 | SN: 1007-1012 |
|||
| ? | 07283-02244 | CLIP | 2 | SN: 2002-3688 |
|||
| ? | 135-60-16480 | CLIP | 2 | SN: 1059-1999 |
|||
| ? | ▩145-49-12270 | U-BOLT | 2 | SN: 1007-1058 |
|||
| ? | (135-60-16480{01599-01011 ?} | ||||||
| ? | 01643-01032(2)) | ||||||
| ? | 01599-01011 | NUT | 4 | SN: 1059-3688 |
|||
| ? | ▩01500-30807 | NUT | 4 | SN: 1007-1058 |
|||
| ? | (01599-01011{01643-01032 ?} | ||||||
| ? | 135-60-16480) | ||||||
| ? | 01602-00825 | WASHER | 4 | SN: 1007-1058 |
|||
| ? | 01643-01032 | WASHER | 4 | SN: 1059-3688 |
|||
| ? | ▩01642-00810 | WASHER | 4 | SN: 1007-1058 |
|||
| ? | (01643-01032{01599-01011 ?} | ||||||
| ? | 135-60-16480) |
