| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 14G-03-21171 | HOSE | 1 | SN: 50001- |
|||
| ? | 208-09-11120 | CLAMP | 2 | SN: 50337- |
|||
| ? | 07281-00809 | CLAMP | 2 | SN: 50001-50336 |
|||
| ? | 14G-03-21141 | TUBE | 1 | SN: 50001- |
|||
| ? | 14G-03-21130 | GASKET | 1 | SN: 50001- |
|||
| ? | 01010-51235 | BOLT | 2 | SN: 50001- |
|||
| ? | 01602-21236 | WASHER,SPRING | 2 | SN: 50001- |
|||
| ? | 07730-50004 | VALVE | 1 | SN: 50001- |
|||
| ? | 07270-01520 | TUBE | 1 | SN: 50001- |
|||
| ? | 07281-00197 | CLAMP | 1 | SN: 50001- |
|||
| ? | 14G-03-21152 | HOSE | 1 | SN: 50001- |
|||
| ? | 205-09-61120 | CLAMP | 2 | SN: 50337- |
|||
| ? | 07281-00909 | CLAMP | 2 | SN: 50001-50336 |
|||
| ? | 14G-03-21320 | BRACKET | 1 | SN: 50001- |
|||
| ? | 01010-51040 | BOLT | 2 | SN: 50001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 50001- |
|||
| ? | 14G-03-21160 | CLIP | 1 | SN: 50001- |
|||
| ? | 01010-51020 | BOLT | 2 | SN: 50001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 50001- |
|||
| ? | 07261-20910 | HOSE | 1 | SN: 50001- |
|||
| ? | 07281-00197 | CLAMP | 2 | SN: 50001- |
|||
| ? | 08036-01814 | CLIP | 1 | SN: 50001- |
|||
| ? | 01010-51025 | BOLT | 1 | SN: 50001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 1 | SN: 50001- |
|||
| ? | 08034-00823 | BAND | 3 | SN: 50001- |
|||
| ? | 14G-03-21270 | TUBE | 1 | SN: 50001- |
|||
| ? | 04059-01010 | WIRE,LOCK | 1 | SN: 50001- |
|||
| ? | 6675-61-7380 | CLIP | 4 | SN: 50001- |
