| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 141-49-33531 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03032 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31030 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 07260-03214 | HOSE | 1 | SN: 20006-@ |
|||
| ? | 07280-05026 | CLAMP | 4 | SN: 20006-@ |
|||
| ? | 141-49-33570 | CASE | 1 | SN: 20006-20021 |
|||
| ? | 01040-31245 | BOLT | 4 | SN: 20006-20021 |
|||
| ? | 01602-01236 | WASHER | 4 | SN: 20006-20021 |
|||
| ? | 144-49-13550 | COVER | 1 | SN: 20006-20021 |
|||
| ? | 01040-31025 | BOLT | 4 | SN: 20006-20021 |
|||
| ? | 01602-01030 | WASHER | 4 | SN: 20006-20021 |
|||
| ? | 07000-02090 | O-RING | 1 | SN: 20006-20021 |
|||
| ? | 145-49-33230 | STRAINER | 1 | SN: 20006-20021 |
|||
| ? | 144-49-13570 | BOLT | 1 | SN: 20006-20021 |
|||
| ? | 01642-21016 | WASHER | 1 | SN: 20006-20021 |
|||
| ? | 01513-31012 | NUT | 1 | SN: 20006-20021 |
|||
| ? | 04050-02022 | PIN | 1 | SN: 20006-20021 |
|||
| ? | 141-49-33541 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03032 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31025 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 07260-03216 | HOSE | 1 | SN: 20006-@ |
|||
| ? | 07280-05026 | CLAMP | 4 | SN: 20006-@ |
|||
| ? | 141-49-33511 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03032 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31030 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 141-49-33521 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03025 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31030 | BOLT | 2 | SN: 20006-20021 |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 141-49-33491 | BRACKET | 1 | SN: 20006-@ |
|||
| ? | 01040-31020 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 07283-03442 | CLIP | 1 | SN: 20006-@ |
|||
| ? | 01554-01011 | NUT | 2 | SN: 20006-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 07283-02236 | CLIP | 1 | SN: 20006-@ |
|||
| ? | 01554-01011 | NUT | 2 | SN: 20006-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 07102-00504 | HOSE | 1 | SN: 20006-@ |
|||
| ? | 141-49-33151 | TUBE | 1 | SN: 20006-@ |
|||
| ? | 07000-03025 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31050 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 07040-01007 | PLUG | 1 | SN: 20006-@ |
|||
| ? | 07000-02008 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 141-49-33650 | SPACER | 3 | SN: 20006-20021 |
|||
| ? | 141-49-33192 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03025 | O-RING | 2 | SN: 20006-@ |
|||
| ? | 01040-31045 | BOLT | 4 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 4 | SN: 20006-@ |
|||
| ? | 141-49-33235 | TUBE | 1 | SN: 20006-@ |
|||
| ? | 07000-03025 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31095 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 141-49-33580 | BRACKET | 1 | SN: 20006-@ |
|||
| ? | 07283-02236 | CLIP | 2 | SN: 20006-@ |
|||
| ? | 01554-01011 | NUT | 4 | SN: 20006-@ |
|||
| ? | 01643-31032 | WASHER | 4 | SN: 20006-@ |
|||
| ? | 07102-00504 | HOSE | 2 | SN: 20006-@ |
|||
| ? | 141-49-33222 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03035 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 01040-31235 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01236 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 141-49-33590 | BRACKET | 1 | SN: 20006-@ |
|||
| ? | 141-49-32480 | CLIP | 2 | SN: 20006-@ |
|||
| ? | 01040-31020 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 141-49-33212 | TUBE | 1 | SN: 20006-@ |
|||
| ? | 07000-03035 | O-RING | 1 | SN: 20006-20021 |
|||
| ? | 01040-31235 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01236 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 141-49-33283 | TUBE | 1 | SN: 20006-20021 |
|||
| ? | 07000-03025 | O-RING | 2 | SN: 20006-@ |
|||
| ? | 01040-31030 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01040-31075 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 4 | SN: 20006-@ |
|||
| ? | 141-49-33620 | ORIFICE | 1 | SN: 20006-@ |
|||
| ? | 07000-02021 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 145-49-13420 | SPACER | 1 | SN: 20006-@ |
|||
| ? | 145-49-13430 | GASKET | 1 | SN: 20006-@ |
|||
| ? | 07000-03030 | O-RING | 1 | SN: 20006-@ |
|||
| ? | 141-49-33161 | TUBE | 1 | SN: 20006-@ |
|||
| ? | 01040-31080 | BOLT | 2 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 01040-31065 | BOLT | 1 | SN: 20006-@ |
|||
| ? | 01040-31045 | BOLT | 1 | SN: 20006-@ |
|||
| ? | 01602-01030 | WASHER | 2 | SN: 20006-@ |
|||
| ? | 144-49-13670 | SPACER | 1 | SN: 20006-@ |
|||
| ? | 144-49-31680 | GASKET | 1 | SN: 20006-@ |
|||
| ? | 144-49-13690 | ORIFICE | 1 | SN: 20006-@ |
|||
| ? | 07000-03028 | O-RING | 1 | SN: 20006-@ |
