| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 141-900-0510 | FRAME ASS'Y | 1 | SN: 45001- |
|||
| ? | 141-900-3211 | • FRAME | 1 | SN: 45001- |
|||
| ? | 144-70-13120 | • • SHAFT (WELDED) | 1 | SN: 45001- |
|||
| ? | 140-70-13130 | • • COLLAR (WELDED) | 1 | SN: 45001- |
|||
| ? | 144-70-13210 | • • BRACKET,L.H. (WELDED) | 3 | SN: 45001- |
|||
| ? | 144-70-13220 | • • BRACKET,R.H. (WELDED) | 3 | SN: 45001- |
|||
| ? | 140-70-00032 | • PIVOT ASS'Y | 2 | SN: 45001- |
|||
| ? | 140-70-13141 | • • PIVOT (WELDED) | 1 | SN: 45001- |
|||
| ? | 140-70-13151 | • • CAP | 1 | SN: 45001- |
|||
| ? | 01011-62430 | • • BOLT | 2 | SN: 45001- |
|||
| ? | 01602-02472 | • • WASHER | 2 | SN: 45001- |
|||
| ? | 130-70-13241 | • • NUT | 2 | SN: 45001- |
|||
| ? | 144-70-00020 | ARM ASS'Y | 2 | SN: 45001- |
|||
| ? | 144-70-12141 | • ARM | 1 | SN: 45001- |
|||
| ? | 144-70-12161 | • • BRACE | 1 | SN: 45001- |
|||
| ? | 144-70-12150 | • • STOPPER (WELDED) | 1 | SN: 45001- |
|||
| ? | 150-70-12120 | • • BUSHING (WELDED) | 1 | SN: 45001- |
|||
| ? | 144-70-12181 | • • PIN (WELDED) | 1 | SN: 45001- |
|||
| ? | 170-70-12150 | • • PIN (WELDED) | 1 | SN: 45001- |
|||
| ? | 170-70-12160 | • • LOCK | 2 | SN: 45001- |
|||
| ? | 150-70-13420 | • • CHAIN | 1 | SN: 45001- |
|||
| ? | 130-70-12221 | • PIN | 2 | SN: 45001- |
|||
| ? | 130-70-12231 | • PIN | 2 | SN: 45001- |
|||
| ? | 04050-05030 | • PIN | 2 | SN: 45001- |
|||
| ? | 150-70-13410 | • PIN | 1 | SN: 45001- |
|||
| ? | 170-70-12240 | • PIN | 1 | SN: 45001- |
|||
| ? | 04050-04025 | • PIN | 1 | SN: 45001- |
|||
| ? | 144-70-00032 | BRACE ASS'Y | 2 | SN: 45001- |
|||
| ? | 144-70-12161 | • BRACE | 1 | SN: 45001- |
|||
| ? | 07020-00000 | • FITTING | 2 | SN: 45001- |
|||
| ? | 130-70-52110 | • SCREW | 1 | SN: 45001- |
|||
| ? | 01602-01442 | • WASHER | 1 | SN: 45001- |
|||
| ? | 140-70-12191 | • BOLT | 1 | SN: 45001- |
|||
| ? | 141-900-3150 | TRUNNION | 2 | SN: 45001- |
|||
| ? | 01010-32045 | BOLT | 16 | SN: 45001- |
|||
| ? | 01643-32060 | WASHER | 16 | SN: 45001- |
|||
| ? | 141-900-4210 | ROD | 2 | SN: 45001- |
|||
| ? | 09241-40120 | PIN | 4 | SN: 45001- |
|||
| ? | 141-900-4120 | BUSHING | 4 | SN: 45001- |
|||
| ? | 04082-00212 | LOCK | 4 | SN: 45001- |
|||
| ? | 07020-00000 | FITTING | 4 | SN: 45001- |
|||
| ? | 01010-31225 | BOLT | 8 | SN: 45001- |
|||
| ? | 01602-01236 | WASHER | 4 | SN: 45001- |
|||
| ? | 141-70-32180 | BRACKET | 2 | SN: 45001- |
