Номер на схеме	Каталожный номер	Название	Количество
?	VE3693	END CAP	1
?	VE3691	HUB, FAN MOUNTING	1
?	VE3696	RETAINER, SEAL (FRONT) (1)	1
?	VE4331	SLEEVE, WEAR (FRONT) (1)/(2)	1
?	VE3685	BEARING, MAIN (FRONT) (1)	1
?	VE1304	PLATE, FACING	7
?	VE3690	HUB, CLUTCH	1
?	VE4418	SNAP RING, EXTERNAL	1
?	VE3692	BEARING, SLEEVE (REAR) (1)	1
?	VE3692	BEARING, SLEEVE (FRONT) (1)	1
?	VE3680	OIL SEAL (FRONT) (1)/(2)	1
?	VE3694	RETAINER, BEARING (FRONT)	1
?	VE3700	O-RING SEAL (1)/(2)	1
?	VE3683	BOLT	8
?	VE3684	LOCKWASHER	8
?	VE1305	CLUTCH PLATE, STEEL	7
?	VE3687	PISTON	1
?	VE3688	RING, SEAL (1)/(2)	1
?	VE3713	PULLEY	1
?	VE3684	LOCKWASHER	8
?	VE3683	BOLT	8
?	VE3700	O-RING SEAL (1)/(2)	1
?	VE3710	RETAINER, BEARING (REAR)	1
?	VE3680	OIL SEAL (REAR) (1)/(2)	1
?	VE3697	SNAP RING, INTERNAL (1)	1
?	VE3689	SEAL RING, SMALL (1)/(2)	1
?	VE3701	SPRING WASHER (1)/(2)	1
?	VE3697	SNAP RING, INTERNAL (1)	1
?	VE3702	SNAP RING, EXTERNAL (1)	1
?	VE3703	SHIM (1)/(2)	1
?	VE3678	SHAFT & BRACKET ASSEMBLY	1
?	TH5103	RING, SEAL (1)/(2)	2
?	VE3711	PITOT TUBES (1)/(2)	2
?	VE3679	SLEEVE, WEAR (REAR) (1)/(2)	1
?	VE1297	FITTING, ORIFICE	1
?	VE3696	RETAINER, SEAL (REAR) (1)	1
?	VE3685	BEARING, MAIN (REAR) (1)	1
?	VE3686	SNAP RING, EXTERNAL (1)	1
?	VS7811	NAME PLATE KIT (1)/(2)	1
?	VS7810	ADJUSTING BRACKET	1
?	VE3684	LOCKWASHER	4
?	VE3695	BOLT	4
?	VE3714	ENGINE INTERCOOLER THERMO SENSOR (120 - 130 DEG)	1
?	VE3715	ENGINE JACKET COOLANT SENSOR (180 - 190 DEG)	1
?	VE3742	NOTE: (1) INCLUDED IN VE3742 OVERHAUL KIT.
?	VE3741	(2) INCLUDED IN VE3741 SEAL KIT.
