| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SM2839 | PLATE, CONNECTOR | 1 | ||||
| ? | EC8892 | HOSE, WINDSHIELD WASHER | 1 | ||||
| ? | EF9155 | HARNESS, CAB MAIN | 1 | ||||
| ? | WA5643 | MACHINE SCREW | 20 | ||||
| ? | EF6786 | GASKET | 3 | ||||
| ? | WB0908 | NUT, CONNECTOR PLATE | 3 | ||||
| ? | EG2913 | HARNESS - ENGINE DIAGNOSTIC | 1 | ||||
| ? | SM0724 | GASKET | 3 | ||||
| ? | SM2120 | NUT, CONNECTOR PLATE | 3 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | HE2467 | MACHINE SCREW - #6 - 32NC X 1/2" | 4 | ||||
| ? | EF6787 | COVER PLATE, CONNECTOR | 1 | ||||
| ? | EF9154 | HARNESS - INTERNAL POWER | 1 | ||||
| ? | WA5642 | MACHINE SCREW | 8 | ||||
| ? | SM0723 | GASKET | 1 | ||||
| ? | SM1841 | NUT, RING | 1 | ||||
| ? | EF9756 | HARNESS - PAYLOAD METER CAB | 1 | ||||
| ? | EC8891 | PLATE, COVER | 1 | ||||
| ? | TF6380 | GROMMET, RUBBER | 1 | ||||
| ? | SM2117 | PLATE, NUT | 3 | ||||
| ? | MM0027 | CAPSCREW - M6 X 1.00 X 25 | 8 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 8 | ||||
| ? | SM2192 | MOUNTING PLATE, HARNESS | 2 | ||||
| ? | SM0721 | GASKET | 2 | ||||
| ? | SM3151 | HARNESS - L.H. WINDOW CONTROLS | 1 | ||||
| ? | SM3152 | HARNESS - R.H. WINDOW CONTROLS | 1 | ||||
| ? | EF9156 | HARNESS - INDICATOR LIGHT CLUSTER | 1 | ||||
| ? | EF9157 | HARNESS - BUDDY SEAT | 1 | ||||
| ? | EF9751 | HARNESS - CAB CIRCUIT BREAKER | 1 | ||||
| ? | PB8256 | SCREW LOCK, FEMALE | 2 | ||||
| ? | SM2773 | PLATE, MOUNTING | 1 |
