| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | C1676 | CAPSCREW | 2 | ||||
| ? | TD0795 | LOCKWASHER - 7/16" | 2 | ||||
| ? | SM2676 | BASE, COMPONENTS | 1 | ||||
| ? | SM3009 | LIGHTER, CIGAR - 12 VOLT | 1 | ||||
| ? | SC5252 | MACHINE SCREW - #8 - 32NC X 3/4" | 1 | ||||
| ? | VM9910 | LOCKWASHER - #8 | 1 | ||||
| ? | TV2179 | NUT - #8 - 32NC | 1 | ||||
| ? | VE2894 | BEZEL | 1 | ||||
| ? | SM0550 | PANEL, SHIFT CONSOLE | 1 | ||||
| ? | VE2590 | TRAY, ASH | 1 | ||||
| ? | SM5110 | SENSOR, ANGLE | 1 | ||||
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 3 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 3 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 3 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 3 | ||||
| ? | PB8639 | SWITCH, ROCKER | 2 | ||||
| ? | TF7982 | GROMMET, RUBBER | 1 | ||||
| ? | PB8624 | SWITCH, PUSH BUTTON | 1 | ||||
| ? | PB6343 | BUTTON, PLUG | 1 | ||||
| ? | PB4060 | SWITCH, PUSH BUTTON | 1 | ||||
| ? | PB6503 | SWITCH, PUSH PULL | 1 | ||||
| ? | PB5957 | KNOB | 1 | ||||
| ? | ED2863 | POTENTIOMETER | 1 | ||||
| ? | TY8745 | SWITCH, CONTROL | 1 | ||||
| ? | WA4513 | SCREW | 9 | ||||
| ? | TZ7321 | NAME PLATE - LICLU | 1 | ||||
| ? | MM0593 | CAPSCREW - M8 X 1.25 X 20 | 10 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 10 | ||||
| ? | SM2224 | SEAL, STRIP | 1 | ||||
| ? | SM0887 | COVER, COMPONENTS BASE | 1 | ||||
| ? | SM2223 | SEAL, STRIP | 1 | ||||
| ? | EF9752 | HARNESS - SHIFT TOWER | 1 | ||||
| ? | SM2222 | SEAL, STRIP | 2 | ||||
| ? | SM2826 | SEAL, STRIP | 1 | ||||
| ? | SM2463 | SEAL, STRIP | 1 | ||||
| ? | SM2827 | SEAL, STRIP | 1 | ||||
| ? | SM2324 | SEALANT | 1 | ||||
| ? | EF9755 | HARNESS, BUDDY SEAT INTERNAL | 1 | ||||
| ? | MM0016 | CAPSCREW - M8 X 1.25 X 16 | 3 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 3 | ||||
| ? | TF6925 | CLAMP | 3 | ||||
| ? | SM2857 | PLATE, BENT | 1 | ||||
| ? | MM0019 | CAPSCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 2 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 2 | ||||
| ? | EF9153 | HARNESS, AID MODULE | 1 | ||||
| ? | PB7004 | AID MODULE ASSEMBLY (A.I.D.) | 1 | ||||
| ? | VE4322 | • BOX (W/O CARDS) | 1 | ||||
| ? | VS5162 | • COVER | 1 | ||||
| ? | VE4107 | • KNOB | 1 | ||||
| ? | VJ8805 | • CARD, FLASHER/COOLANT LEVEL | 1 | ||||
| ? | VJ8806 | • CARD, TEMPERATURE | 1 | ||||
| ? | VJ9023 | • CARD, DIODE (W/SOUND) | 1 | ||||
| ? | VJ9024 | • CARD, DIODE (W/O SOUND) | 1 | ||||
| ? | PB5672 | • CARD, SINGLE TEMPERATURE LATCH | 1 | ||||
| ? | TS0299 | • RESISTORS | 2 | ||||
| ? | TY7846 | • HOUSING | 1 | ||||
| ? | TZ0951 | • HOUSING, LEVEL | 1 | ||||
| ? | MM0582 | MACHINE SCREW - M6 X 1.00 X 20 | 4 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | TZ7319 | NAME PLATE - RD1 | 1 | ||||
| ? | TZ7320 | NAME PLATE - RD2 | 1 | ||||
| ? | MM0718 | NUT - M8 X 1.25 | 1 | ||||
| ? | MM0711 | FLAT WASHER - M6 (HARDENED) | 4 | ||||
| ? | PB6121 | CARD, OIL LEVEL TEMPERATURE | 1 | ||||
| ? | VJ9025 | CARD, DUAL HOT SWITCH INVERTER | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | TS0299 | RESISTOR, 2K | 2 | ||||
| ? | TY7846 | HOUSING, TEMP. | 1 | ||||
| ? | TZ0951 | HOUSING, COOLANT LEVEL | 1 |
